multi layer fr4 enig hals printed pcb circuit board

FOB Price

USD $3.99 - $6.99 / Piece

10 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	KEYOU		Place of Origin	China
Model Number	MPKY-02B

We Offer a Full Range of Printed Circuit Board Capabilities to Fit All of Your PCB Needs

Process	Item	Craft Capacity
Prepares materials	Base Material	FR4, CEM-1, Aluminium, High Tg Material, Halogen-free Material
Lamination press	Layer Count	1-12Layers
	Thickness	0.2-3.0mm
Drill	Min.Hole Diameter	0.15mm (mechanical drill), 0.1MM (laser drill)
	PTH Diameter Tolerance	+ / - 3mil
	NPTH Diameter Tolerance	+ / - 2mil
Outer layer	Min.Line/Space	3.5mil/3.5mil
	Copper Thickness	1- 6oz
Impendence	Impedance tolerance	±10% (±5%(Need assessment)
Solder Masking	Min.Solder Dam	0.1mm
	Min.Solder Mask Opening	0.075mm
	Color	Green, White, Red, Yellow, Black, Blue
Surface Treatment	LF-HASL, OSP,Ni/Au Enig,Immersion Tin, Immersion Silver, carbon oil;
Out-Line Profiling	Profile Tolerance	+ / - 0.12MM
	V-cut Remain Thickness Tolerance	+ / - 0.1MM
	V-cut Angle Tolerance	+ / - 5°
Testing	E-Testing	100% E-Testing (High Voltage Testing); Flying Probe Testing
Final Product	Thickness Tolerance	+ / - 10%
	Warpage Tolerance	+ / - 0.75%

Lead Time	Double layer PCB	Multilayer PCB	Mass production
	Normal 6 work days	Normal 8 work days	Double layer 9-12 work days
	Urgent 3 work days	Urgent 6 work days	Multilayer 12-15 work days
