Woodworking dust collector for furniture factory

The special woodworking dust collector for furniture factory solves the fine wood flour produced by various polishing machines. After the bag dust collector sucks these fine dust away, the harm of dust to human body is effectively avoided. The workers in the factory have removed the title of Pulsatilla chinensis, the production environment has been greatly improved, and the production efficiency has also been significantly improved. We have high praise!

2. Because the sawdust is fine and dry, it is easy to cause fire. After use, the fire is avoided.

3. At the same time, from the two-year use effect, after the dust is absorbed, it reduces the normal wear and tear of suspended dust on equipment, prolongs the life of equipment, and reduces the maintenance cost.

The advantages of DMC48 pulse bag filter are as follows:

DMC48 pulse bag filter made by Fudong environmental protection dust collector is a dust collector specially designed and manufactured for wood dust treatment according to the characteristics of fine, dry and light weight of wood dust in furniture workshop. The structure and pulse valve of the original MC dust collector have been improved, so that the equipment has high purification efficiency, high gas handling capacity and stable performance. It has the advantages of easy operation, less maintenance workload and lower labor intensity of operators.

Measures for collecting wood dust in furniture factories:

Each processing machinery dust source is equipped with a dust hood above or laterally. The dust is sucked into the conveying pipeline through the action of a fan and then sent to the storage bin. The dust concentration at each operating point can be reduced to 2 mg/m3. The dust removal efficiency is over 95%-99%.

Why do customers choose the dust collector of Fudong Environmental Furniture Factory?

Customers choose our equipment based on the avoidance of fine, dry dust. Light dust causes pollution and fire, and in order to collect valuable sawdust well, we choose to order special dust collector, then we choose Fudong environmental protection. Because Fudong Environmental Protection Company has mature experience and has done a lot of cases, the customer response effect is good.

At the same time, the company's furniture factory dust collector has unique advantages:

(1) Postpositioned negative pressure is used for ventilation, and the suction effect is excellent!

(2) The company strictly checks the quality of products, and the amount of equipment maintenance is small.

(3) Dust removal bag with high quality, good air permeability and long service life.

Woodworking bag dust collector is used in woodworking workshop, grinding workshop and paint workshop. It is a special device consisting of pipes, fans and filters to remove sawdust and paint dust produced in the process of processing.

Woodworking bag filters are classified as follows according to device and dust removal method:

According to the device mode:

1. Indoor dust collector: including ordinary bag cleaner, pipeline filter

2. Outdoor Dust Collector: Direct Falling Dust Collector, Pulse Modular Dust Collector

According to the way of dust removal:

1. Positive Pressure Dust Removal

2. Negative Pressure Dust Removal

Dust removal principle of woodworking bag filter:

The airflow containing sawdust particles is conveyed to the diversion bin of the bag filter through the fan. The airflow velocity decreases under the action of the diversion plate. The heavier sawdust particles fall into the ash bin under the action of gravity. The other lighter dust adsorbs on the outer surface of the bag with the airflow upward. After the filter of the bag, the clean gas enters the exhaust chamber and drains out side by side. With the continuous filtering conditions, more and more dust will accumulate on the outside surface of the filter bag, which will increase the operating resistance of the system and reduce the dust removal efficiency of the system. Therefore, the system is equipped with an automatic pulse ash removal device, which consists of pulse controller, pulse valve, speed linkage, drum and spray pipe. According to the characteristics of sawdust particles, the pulse amplitude and frequency can be set on the pulse controller. After setting the pulse amplitude and frequency, the system will automatically clean the filter bag during the working process, thus greatly increasing the same filtering efficiency and prolonging the service life of the filter bag.

Woodworking dust removal can not be without three devices, pipeline system, fan system, filtration system. In these three systems, different configurations have different structures and functions, but the basic principles are the same, just like people wearing masks. The pipeline is connected with woodworking machinery and filtration system, and the work of fan makes the pipeline produce negative pressure dust collection. The most important is the configuration of the fan and the performance of the filter bag.
