SYNTEC Servo Control System cnc milling machine for aluminum profile 3 axis milling drilling machining center
- 1 Set / Sets per Month
- Qingdao Port
- T/T Credit Card
You May Like
-
Exhibition hot sale cnc gantry milling machine
-
Automatic tool change micro cnc milling machine
-
Maxicut Milling Machine 3 axis cnc processing center for aluminum profile machining center
-
Exhibition hot sale cnc milling drilling tapping chamfering machines
-
SYNTEC Servo Control System aluminum profile milling machinery price in india
-
Exhibition hot selling machine 3 in 1 lathe drilling and milling machine
Product Details
Brand Name | MMCNC / MAXICUT | Model Number | SKX-CNC-1200 |
Standard Export Wooden Cases
Product Description
SYNTEC Servo Control System cnc cnc milling machine for aluminum profile 3 axis milling drilling machining center for aluminum profile 3 axis milling drilling machining center
1. Feature
1.1 Applicable for drilling holes, milling grooves, processing circular holes and special-shaped holes, plane engraving of aluminum alloy profiles.
1.2 System adopts Taiwan Syntec CNC controller.
1.3 Adopting electric spindle; high precision, high safety and reliability
1.4 X axis adopts high-precision helical gear and rack; Y and Z axis adopt high-precision ball screw transmission; steady transmission and high precision.
1.5 By using programming software to automatically transform and process G code; easy operation; high efficiency and low labor intensity.
1.6 Workbench can turn 180°, -90°~0 °~+90°; It can realize three-sides processing by clamping one time; it can process deep and special-shaped holes through workbench; high efficiency and precision.
2. Specification
Parameter |
|
Air Pressure | 0.5~0.6MPa |
X/Y/Z Axis stroke | 1200mm*300mm*280mm |
Input Voltage | 380V 50Hz or As Customer need |
Input Power | 3Kw |
Handle type | ER25*Φ8 |
Processing range | 100*140 |
Overall size | 2200×1500×19500mm |
Weight | 700kg |
Main accessory |
|
Control system | Taiwan Syntec |
Solenoid valve | Germany FESTO |
Cylinder | PC(FESTO Joint Venture Brand) |
Motor | Anhui Sanyang (Best Chinese Motor Brand) |
Air Filter Device | STNC |
Electrical Button and Switcher | Schneider |
AC Contactor and Circuit Breaker | Schneider |
Approach Switch | Taiwan Delta |
Guide rail | Taiwan Hiwin |
Standard accessory |
|
Cutters | 4pcs |
Air Gun | 1pc |
Complete tooling | 1set |
Certificate | 1pc |
Operation Manual | 1pc |
3. Detailed Photo
The machine was in Shanghai Exhibition with 3000mm length:
Packaging:
1. Standard export cases
2. Special package: according to buyer's requirements
Shipping:
1.The packages suitable for international transport by sea, by air or any other delivery methods
2. Shipping by sea with CFS/CFS from Qingdao sea port or for your requirement.
Mingmei of Service:
Vow to become the best cooperation partner of customers
1. Per-sales services: Porvide accurate and detailed production and set up a service hotline to offer 24 hour inquiry service.
2. In-sales service: The professionals answer all the questions of customers during purchasing and provide helpful suggestions.
After-sales service: Specifically fulfill the after sales commitments to the customers and evisit the customers regularly or irregularly to enhance relations with old and new customers.
Shandong Mingmei CNC Machinery Co., Ltd. was founded in 1995, located in Jinan economic dev. Zone. Company cover an area of 70000 square meters and 200 staffs.
As leading manufacturer of industrial aluminum equipment which is a modern private enterprise specialized in technology development, machinery manufacture and machine sales.
MMCNC machine include Processing machine for making aluminum PVC window and door as well as curtain wall, such as Double-head Cutting Saw; Corner Crimping Machine; End miller; Copy Router; PVC Welding Machine; Corner Cleaning Machine; we also produce CNC Router etc.
We have advanced machining centers, large planer, horizontal boring machine and other specialized machine equpipment, realize the specialized and scale model manufacturer.
We have more than 30 marketing service institutions in China, so can provide promptly after sale service for customers. With all kinds of excellent mechanical processing equipment more than 100 sets.
Select Mingmei CNC, tomorrow will be better.
