Home > Products > Pipe bending machine > Single head hydraulic luggage and suitcase aluminum profile bending machine
Single head hydraulic luggage and suitcase aluminum profile bending machine
- 30 Set / Sets per Month
- Shanghai China
- T/T Credit Card
You May Like
-
3D simulation automatic cnc pipe tube bending machine, furniture tube bending machine, mandrel tube push bending machine
-
DW25-SX Manual portable hand operate pipe bending machine, mini simple hand tube bending machine
-
DW25-SZ Manual portable hand operate pipe bender machine with rotating angle scale, portalbe hand tube bender machine
-
SW50A price of double end bending machine, twin head tube bending machine, double head hydraulic bender machine
-
DW50CNC automatic 3d aluminum tube bender, steel pipe banding machine price, automatic pipe bending machine
-
Auto mandrel simulation 3d tube bender, aluminum pipe bender, automatic exhaust tube bending machine
Product Details
| Brand Name | CARE | Model Number | SW38CNC aluminum profile bending machine |
Product Description
Single head hydraulic luggage and suitcase aluminum profile bending machine
Main specification
1. Interactive PLC touch screen offers easy access to auto and manual operating modes.
2. System diagnostics and multiple language capability.
3. Standard clockwise bending direction.
4. Fully hydraulic clamping on clamp die and pressure die.
5. Drop-way hydraulic clamping.
6. Direct acting hydraulic pressure die with adjustable speed valve.
7. Maximum 99 sets of program storage,Maximum 32 bends for each program.
8. With Independent programmable speeds Y, B, and C axes.
9. Programmable material spring back settings for each bend angle.
10. Automatic release of tube prior to final bend.
11. Bending Axis-Driven by Cylinder,Feeding Axis-Driven by Servo Motor,Rotating Axis-Driven by Servo Motor.
12. Obtain quality repeatable bends in steel, stainless, aluminum, titanium and brass.
13. Foot Pedal Cycle start.
14. With Air Cooling System.
15. One set of Tooling for Draw Bending.
16. Wiper die Bracket.
17. 1 Mandrel Rod.
18. Operation and Maintenance Manual.
19. Tool Box with Adjusted Tools.
20. Electric: As required
Technical parameter
Bending radius | R25-R150 |
Max bending angle | 150 |
Main power | 5.5Kw |
Machine weight | 1200kgs |
Max feeding stroke | 2800mm |
Machine photo
Pipe samples
