Home > Products > Dock Leveler Ramp > 7LYQ Shandong SevenLift 10000kg ground container legs loading unloading dock trailers access ramp

7LYQ Shandong SevenLift 10000kg ground container legs loading unloading dock trailers access ramp

FOB Price

USD $4,500 - $4,500

1 (Min.Order)

Supply Ability 1000 per Month
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	SevenLift	Place of Origin	Shandong, China
Certification	ISO	After-sales Service Provided	No overseas service provided
Warranty	12 Months	Weight	3000kg
Power	Manual	Rated Loading Capacity	10000kg
Overall Dimensions	10.8x2x1.1m	Min. Lifting Height	1m
Max. Lifting Height	1.7m	Table Size	10.8x2m
Lift Drive / Actuation	Hydraulic	Lift Mechanism	Telescoping Lift

Product Description

Product Application

The 7LYQ Shandong SevenLift 10000kg ground container legs loading unloading dock trailers access ramp is the special auxiliary equipment used for loading and unloading of goods which is widely used in warehouse, station, wharf, warehousing logistics base, postal transportation, logistics distribution etc. Its height can be adjusted with the different heights of lorries. Some transport vehicles like forks can directly move into the wagon box with goods in using it, and only need one person operating.

7LYQ Shandong SevenLift 10000kg ground container legs loading unloading dock trailers access ramp
Hydraulic Ramp Specification	Max Height	+1700mm
	Min Height	+1000mm
	Load Capacity	10T
Hydraulic Ramp Material	Ramp Size	10.8x2m
	Work	Manual
	Wheel	non-pneumatic tyre
Hydraulic Ramp Safety	Overload Protection	If overload, the ramp will not work
	Manual Down Device	It can be lowered by manual down valve in case of power failure
	Self Height	1000mm

Product Features

Fully hydraulic operation (both deck and lip)
Self-retracting lip assembly
Fixed rear hinge assembly facilitates deck canting
Local voltage can be customized (110V, 220V, 380V)

SevenLift Workshop

Detailed Images

Material

SevenLift mobile ramp with strength material frame.

Support legges

Hydraulic system, SevenLift mobile ramp with strength legges material.

Mobile ramp flap

SevenLift mobile ramp to make the forklift goes fluently.

Two wheels

SevenLift mobile ramp with two non-pneumatic tyres.

Our Service

Pre-Sales Service

* Inquiry and consulting support.
* View SevenLift Factory.
* SevenLift Trade Assurance

After-Sales Service

* Training how to install and how to use the lift.
* One year warranty.
* SevenLift spare parts is available all the time.

Packing & Delivery

Packaging
SevenLift Delivery	Ship by sea
Port	Qingdao, other ports is available.
Delivery Details	One set in a 20' container. 3 sets in a 40' container. Tell us your near port or any other way you prefer.

FAQ

Questions about 7LSJG Jinan SevenLift 10000kg ground container legs loading unloading dock trailers access ramp

Q1. Can I have a sample model?
A:Our 10000kg ground container legs loading unloading dock trailers access ramp for sale is customized based on your detail request, you can buy one for your testing at first.
MOQ 1 set is available.
Q2. What about the delivery time?
A: It usually takes about 20 working days after we receive the deposit.
Q3. What kind of payment do you support?
A: T/T, L/C, West Union, Alibaba Trade Assurance. T/T is usually.
Q4. How to proceed an order for the lift?
A: Firstly, tell us your requirements, if you can send a photo where you will use the lift, it will be better.
Secondly, we send you our suggestions and quote according to the practical situation.
Thirdly, you confirm the quotation along with your request details and places deposit.
Then we arrange the production. Once we finish the production, we will send photos for your reference.
Q5. How to transfer the lift machine?
A: It is usually shipped by sea. Plywood package and LCL in a 20' container.
The ship has to be booked one-week before, and shipping time is usually longer, please be patient.
Q6. Is it OK to print my LOGO on the lift?
A:Yes. Please inform us formally before our production and send us your high pixel LOGO.
Q7: How to deal with the broken?
A: Firstly, our products are produced in strict quality, we must test it before we sending out each machine.
Secondly, we will buy an Insurance for any CIF product to make sure the lift safety in shipping.
If any parts broken, you can tell us, we have one year warranty and free send you a new spare parts and we supply technical supporting all the times.
