Four Head Welding UPVC Profile Window Door Making Machine
- Qingdao or any port of China
- T/T Credit Card
You May Like
-
Four Head Seamless Welding Window UPVC Profile Machine
-
Windows UPVC Two Head Welding Profile Machine
-
Window Door PVC Profiles Welding Machine Single
-
Automatic Welding Machine UPVC Windows and Doors
-
UPVC Window Double Corner Welding Machine Profile
-
Single Corner Seamless Machine for Welding UPVC Windows Doors
Product Details
| Brand Name | Better | Model Number | HJ02-4500.4A |
Product Description
Four head welding UPVC profile window door making machine,Model:HJ02-4500.4A
The machine is used for welding PVC UPVC window frame corner, with PLC control and pneumatic driving system, it has the features of high reliability, large process range,high efficiency and easy operation, the four heads can work individually,simultaneously and.The machine should be installed in the workshop where the air is dry,noncorrosive, free of any dirt, and temperature is 10--40°C.
Working Air Pressure | 0.4-0.6Mpa |
Air Consumption | 200L/min |
Power Supply | As required |
Input Power | 4.5kw |
Welding Length | 400-4500mm |
Welding Profile Height | 20-120mm |
Welding Profile Width | ≤120mm |
Welding Mullion Width | ≤120mm |
Outside Dimension | 5300*1000*1700mm |
Weight(about) | 1600kg |
Double head / single head cutting saw
One / two / three / four head---normal & seamless welidng
Lock hole milling machine,Water slot milling machine
End milling machine,V notch saw,glazing bead cutting saw
Call / Wechat:008615168813950
Skype:gorge.zhou
Whats app:008618606396657
