Automatic Thermal Break Aluminum Machine Profile Knurling and Strip Feeding

 Performance and feature

- This is the key equipment for strengthening the resistance of the thermal break and aluminum profile against shearing stress. Notch

  for thermal break on profile is knurled through high rotational speed knurling force.

Specifications

-  Power supply:                      380V  50 Hz

-  Motor power ( two sets):              0.75 kw x 2

-  Rotational speed of spindle:           1400 rpm

-  Cutter placement:       on right and left symmetrically

-  Adjustable angle range of cutter:        0 - 10º

-  Blade diameter:                     100 mm

-  Cutter moving mode:       Horizontally/vertically, two cutters can be adjusted respectively.

-  Cutter moving range:       Horizontally: 130 mm x 2;   vertically: 180 mm

-  Profile feeding:           Automatic advance and retreat  30 m/min.

-  Notch knurling:           Two lines, central distance of slot: mini. 6 mm;  max. 240 mm

-  Max. size of profile:                   240 mm x 170 mm

-  Dimensions:                         1350 x 690 x 1600 mm

       -  Weight:                              230 kg

Factory direct supply, all goods can be customized

OEM/ODM is availibale

Welcome to share your idea with us!

Our engineers can go to your factory for installation, commissioning and training!
