Deep hole honing machine for hydraulic cylinder
- 30 Set / Sets per Month
- Tianjin
- T/T L/C
- 4 days
Product Details
| Brand Name | Guanlu | Place of Origin | China | |
| Model Number | TMK20125x2500mm | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | 1 year | Weight | Machine actual weight | |
| Dimension(L*W*H) | Machine actual size | Voltage | 380v or Follow customer's request | |
| Certification | CE ISO | Condition | New | |
| Power(W) | 30 KW | CNC or Not | CNC |
Product Description
Horizontal Honing machine
Machine brief:
The bed is made of high quality cast iron, which has good precision retention and stability.
The guide rail for the workpiece and tool movement is square rolling linear guide, which has good accuracy and rigidity.
The servo spindle motor is driven by the speed reducer to drive the main shaft to rotate, and the spindle can realize stepless speed regulation.
The servo feed motor drives the gear rack structure through the reducer, so that the cutter can advance or retreat according to the set speed.
Servo motor drives mechanical mechanism to control the change of honing head diameter.
The workpiece is fixed on the workpiece bracket by the positioning sleeve, and the axial position of the workpiece bracket can be adjusted manually.
The machine is equipped with simple safety guard.
Cutting oil supply system: It is equipped with magnetic and paper bag filter.
The machine adopts PLC control.
Machine Mainly Parameters:
Specification | Parameters | Notes | ||
Working capacity | Machining diameter range | Φ7~Φ25mm | ||
Max.machining depth | 2500mm | |||
Max.length of workpiece | 2500mm | |||
Workpiece outer diameter range | Φ25~Φ70mm | |||
Max. Draw ratio | 65:1 | |||
Machine performance | Z axis | Infeed speed range | 1~15m/min | Stepless |
Infeed motor power | 2.8KW | |||
Honing rod box | Speed range | 50~500r/min | Stepless | |
Motor power | 1.1KW | Servo spindle motor | ||
Cooling system | Max.flow | 38L/min | ||
Oil tank capacity (roughly) | 300L | |||
No. | Name | Manufacturer |
1 | Rack | Taiwan |
2 | Servo infeed motor | Domestic brand |
3 | Spindle bearing | NSK |
4 | Mainly electric components | Siemens or Schneider |
5 | Main motor | Beijing CTB |
6 | Linear guide rail | Taiwan TBI or coequality brand products |
7 | Reducer | Taiwan |
Packing :Standard export package
Dezhou Guanlu Precision Machinery Co., Ltd. located in Dezhou, Shandong, is a professional manufacturer of deep hole drilling machine (gun drilling machine), deep hole boring machine, deep hole drilling and boring machine, deep hole honing machine, deep hole skiving roller and burnishing machine as well as their relative accessories, such as gun driller sharpen device, BTA deep hole indexable drill head, deep hole boring head, deep hole pressing head and so on. Our company can also offer the customized deep hole machine solutions according to the customers' requirement.
In order to equips suitable deep hole machine tools for our customers, we have workshop to manufacture the cutting tools and accessories. So customer can inform the exactly deep hole diameter and workpiece dimension, we can provide the cutting tools and accessories to them accordingly.
Welcome to visit our factory. And thanks for choosing our deep hole machinery.
Any question about deep hole machine , feel free to ask me !
