Home > Products > Road Construction Machinery > Brand New Small Motor Grader for Sale With Good Price
Brand New Small Motor Grader for Sale With Good Price
US$ 36,000 - 40,000
/ Unit
1 Unit(Min. Order)
- SHANGHAI
- T/T Credit Card
You May Like
-
China Small Motor Grader Brand New Motor Grader GR135 for Sale
-
Hot Sale GR135 Unction of Motor Grader With Hydraulic Pump for Sale
-
China High Quality Hot Brand Small Motor Grader GR135 Price List
-
China Road Machinery New Motor Grader Gr135 for Sale
-
Good Quality 135hp Motor Grader Mini New Motor Grader GR135
-
Motor Grader Price List Brand New GR135 Best Price
Product Details
| Place of Origin | Jiangsu, China | Certification | ISO CE | |
| Dimension(L*W*H) | 8015*2380*3050mm | |||
| Condition | New | Reverse Speed(km/h) | 40 | |
| Forward Speed(km/h) | 42 |
Product Description
Brand New small motor grader for sale with good price
Please Contact
Steven Zheng
Newindu E-Commerce (Shanghai) Co.,Ltd.
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China
Mobile / Whatsapp/ Wechat: +86-13063433538
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China
Mobile / Whatsapp/ Wechat: +86-13063433538
Email: Steven at
Web:
Web:
Product Description
Main parameter:
Operating weight :11.2 tons ,
Moldboard : 3660×610mm,
Detailed configuration
* 6BT5.9-C130-IIengine,
* Imported differential mechanism .
Advantages
Strong power ,Comfortable driving environment .
Adopt imported hydraulic parts .Great working performance .
Basic Specification
| Model | GR135 |
| Engine Model | 6BT5.9 |
| Rated Power/Speed | 100/2200kw/rpm |
| Dimension(L*W*H) | 8015*2380*3050mm |
| Operating Weight | 11000kg |
Main Performance
| Travelling Speed(forward) | 5,8,13,20,30,42km/h |
| Travelling Speed(reverse) | 5,13,30km/h |
| Tractive Force(f=0.75) | 61.3kN |
| Max.Gradeability | 20% |
| Tire Inflation Pressure | 300kPa |
| Working Hydraulic Pressure | 16MPa |
| Transmission Pressure | 1.3-1.8MPa |
Operating Specification
| Max. steering angle of front wheels | ±49° |
| Max. lean angle of front wheels | ±17° |
| Max. oscillation angle of front axle | ±15° |
| Max. oscillation angle of balance box | 16 |
| Frame articulation angle | ±27° |
| Min. turning radius using articulation | 6.6m |
Biade
| Maximum lift above ground | 410mm |
| Maximum depth of cutting | 535mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 28°-70° |
| Circle reversing rotation | 360° |
| Moldboard width X height | 3710*610mm |
