Hot Sale Mini Road Asphalt Paver with Competitive Price

FOB Price

US$ 110,000 - 111,000 / Unit

1 Unit(Min. Order)

Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Newindu	Place of Origin	Jiangsu, China
Certification	ISO CE
Warranty	1 Year	Weight	450-700kg
Dimension(LWH)	623025003855 mm	Production Capacity	0-14m/min
Condition	New	Power(W)	118kw
Max. Paving Thickness	350mm

Product Description

Hot Sale Mini Road Asphalt Paver with Competitive Price

Please Contact

Aring Zhou

Email: aring @newindu.com

Wechat/Whatsapp/Mobile: +86 15855426352

Skype: zyy1520724641 @outlook.com

Main Parameters

Item	RP952	Unit
Basic Paving Width	3	m
Max. Paving Width	9.5	m
Max. Paving Thickness	350	mm
Paving Speed	0~16.5	m/min
Travel Speed	0~2	km/h
Theoretically Productivity	700	t/h
Hopper Capacity	14	t
Gradeability	20	%
Flatness	3	mm/3m
Error of Lateral Slope	±0.03	%
Adjusting Range of Camber	-1~+4	%
Diesel Engine Model	SC8D190G2B1
Diesel Engine Power	140	kw
Diese Engine Speed	2300	r/min
Total Weight	21.3~28.8	t

Product Description

Feeding technology: reliable and endurable
Large range of the clearance adjusting of the separate rod (330-480mm) meets the requirements of different paving conditions and reduces the segregation along the height direction.
It adopts Φ420X360 large diameter and coarse pitch blade, reducing the rpm and segregation.
Two reverse blades in material separate box reduce the medium segregation area.
Center cooling technology: advanced and unique
With the optimized configuration and optimal cooling performance, the combined cooling water tank is 50% large than the standard water tank of the diesel engine, which could ensure the machine working constantly in high temperature.
The diesel engine and the cooling system adopt the unique closing structure.
The heat of the machine is discharged forcefully.
Screed technology: mature and reliable
The most mature and reliable screed
The screed devices are of many kinds and multiple functions, and the optimal screed is selected according to the requirement of the user.
Dual-vibrating mechanisms could get the excellent compaction on the stabilized material.
The stepless and adjustable vibrating frequency could meet the requirements of various conditions.
Electric heating or gas heating is selected according to the requirement of the user.
Precise allocation
The key parts adopt the high strength materials: the bottom plate and protective devices adopt the imported high endurance steel plate from Germany.
High reliable power and transmission.
RP951A/RP902 is equipped with BF6M1013E engine, 137KW; RP952 is equipped with Shangchai D6114 diesel engine, 140kW; and the optimal is162kW. They could meet the requirements of different users.
Advanced technology
Triune travel and drive device features high reliability and convenient service.
One machine, multiple applications. It can pave the asphalt mixture, lime-flyash soil and stabilizing soil.
Simple operation
The control system adopts micro-computer controlling, featuring simplicity and convenience.
All control components are installed on the instrument box, easy to access.
The seat could be moved to outside featuring excellent visibility.
Easy maintenance
Integrated lubrication device prolongs the service life of the bearings on the positions in high temperature, and reduces the maintenance work.
The diesel engine hood adopts the spring lifting, which is easy for service; the cabin adopts the spring to descend and lift up, which is easy for transportation.
The side hood and diesel engine hood are easy to open, and the components often maintained are easy to access.
The pressure-testing points are distributed reasonably, and easy and rapid to measure.

Product Image
