Competitive Price SANY 650 Ton Crawler Crane SCC6500A With High Efficiency Engine Adopted
- Shanghai Port
- T/T Credit Card
You May Like
-
8t SANY Gantry Luffing Jib Rail Mounted Tower Crane SYT80 T6510-8
-
Affordable 10 Ton SANY Tower Crane Joystick SYT160 SYT160 T7015-10 on Building
-
SANY 8t Self Erecting Mobile Tower Crane SYT80 T6510-8
-
8t SANY 125t.m Good Price Tower Crane SYT125E2(T6515-8) With Optimal Structure Design
-
40 Ton Mobile New Truck Crane QY40K for Sale
-
25 Ton Truck Crane QY25K-II for Sale
Product Details
| Brand Name | SANY | Place of Origin | Hunan, China | |
| Model Number | SCC6500A | Certification | CE/ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | 12 Months | |
| Application | Construction | Condition | New | |
| Max. Lifting Load | 650ton | Span | 46 | |
| Rated Lifting Moment | 3920Ton.m | Rated Loading Capacity | 650ton | |
| Max. Lifting Height | 192m |
Product Description
Competitive Price SANY 650 ton Crawler Crane SCC6500A with High Efficiency Engine Adopted
| Model | SCC6500A | |
Main Performance | Max. rated lifting capacity | 650t/5.5 m |
| Max. lifting moment | 3920 t.m | |
| Max rated lifting capacity with superlift | 650 t / 10 m | |
| Max lifting moment with fixed jib | 2800/5700 tm | |
| Max lifting moment with luffing jib | 3504/8175 tm | |
| Max lifting moment with superlift | 8600 tm | |
| Boom length | 24-96m | |
| Fixed jib length | 12-36 m | |
| Luffing jib length | 24-66m | |
| Combined boom length | 66-114m | |
| Longest (boom+luffing jib) | 96+96 m | |
| Boom length with superlift | 36-108 m | |
| Combined boom length with superlift | 90-144 m | |
| Luffing jib length with superlift | 24-96 m | |
| Boom luffing angle | 30°-85° | |
| Jib luffing angle | 15°-75° | |
| Speed | Rope speed of main/auxiliary winches | 130/120 m/min |
| Rope speed of boom/jib luffing winches | 56×2 / 120m/min | |
| Rope speed of superlift luffing winch | 125 m/min | |
| Single rope pull | 17.8 t | |
| Rope diameter | Φ28 mm | |
| Travelling speed(high/low speed) | 0-1.0/0-0.3 km/h | |
| Slewing speed(no load) | 0-0.8 rpm | |
| Gradeability(with basic boom and driver’s cab backward) | 15% | |
| Engine | Model | QSX15-C600 |
| Rated power | 447/1800 KW/rpm | |
| Rated torque | 2542/1400 Nm/rpm | |
| Transportation | Crane weight | 515 t |
| Max transport weight of single part | 65 t | |
| Maxtransport dimensions | 13290×3000×3200 mm | |
| Average ground pressure | 0.15 Mpa | |
Powerful lifting capacity
SANY SCC6500A crawler crane is powered by Tier 3 engine with rated power of 447Kw @ 1,800rpm, max. output torque of 2,542N·m @ 1,400rpm. The max.lifting capacity is up to 650t @ 5.5m radius, and the max.lifting capacity with superlift is 650t @ 10m radius.
Hoisting and luffing mechanisms
A variable hydraulic motor drives the planetary gear reducer to control the lifting and lowering of main hoists, with rope speed on the outermost work layer of main and auxiliary winches reaching 130 m/min and 120 m/min respectively.
Drums with fold-line grooves are adopted for all luffing devices, with rope speed on the outermost work layer of the boom luffing 56×2 m/min, jib luffing 120 m/min, and superlift luffing 125 m/min.
Slewing gear
Dual-motor is adopted for the swing hydraulic system to drive the spur gear drive through a planetary gear reducer and enables 360° rotation. The swing speed is 0--0.8rpm.
Crawler assembly
Each track frame is equipped with an independent travel driving device. Sufficient traction is provided in low speed to realize 100% pick and carry, while faster job-site transfer is possible in high travel speed.
