2017 Newly Launched 400 Ton Crawler Crane SCC4000A in Excellent Working Conditions
- Shanghai Port
- T/T Credit Card
You May Like
-
Competitive Price SANY 650 Ton Crawler Crane SCC6500A With High Efficiency Engine Adopted
-
8t SANY Gantry Luffing Jib Rail Mounted Tower Crane SYT80 T6510-8
-
Affordable 10 Ton SANY Tower Crane Joystick SYT160 SYT160 T7015-10 on Building
-
SANY 8t Self Erecting Mobile Tower Crane SYT80 T6510-8
-
8t SANY 125t.m Good Price Tower Crane SYT125E2(T6515-8) With Optimal Structure Design
-
40 Ton Mobile New Truck Crane QY40K for Sale
Product Details
| Brand Name | sany | Place of Origin | Hunan, China | |
| Certification | CE/ISO9001 | |||
| Warranty | 1 Year | Application | Construction | |
| Condition | New | Span | 30-85 | |
| Rated Lifting Moment | 2560Ton.m | Rated Loading Capacity | 400t | |
| Max. Lifting Height | 84m |
Product Description
2017 Newly Launched 400 ton Crawler Crane SCC4000A in Excellent Working Conditions
SCC4000A crawler crane features wide adaptability and high safety, is your best choice for applications in wind turbines lifting, shield machine and common luffing jib operating conditions.
Powerful lifting capacity
Max load of 84m boom and 12m fixed jib @ 16m radius is up to 106t, max load of 90m boom and 12m fixed jib @ 17m radius is 95t, and for shield machine lifting, the SCC4000A can lift 130t machine with 6.5m diameter alone.
Easy transportation
3 modes of transport are available with transport weight of 45t, 55t and 60t, transport width of 3m, transport height of 3.2m, which make sure the crane can be transferred long distance, in mountains or port shipment.
Quick assembly and disassembly
The boom and jib structure of SANY crawler cranes are interchangeable, which can save the costs.
Optimized hoisting and luffing mechanisms can realize quick assembly and disassembly of boom, jib, and superlift devices.
Sany SCC8300 crawler crane's maximum lifting capacity is 300 tons, with multifunctional boom system, the crane may support a combination of up to 11 types of operating conditions. The 300 ton crawler tower suits for various business requirements.
Superior Performance
International Standards
QSM11 engine with rated power of 298kW (400hP) @1800rpm complies with EPA Tier 4 and EU IV emission standards and delivers powerful and environmentally friendly power.
The crane also complies with the European 2000/14/EC directive about noise emission by equipment for use outdoors, and its vibration meets the requirement of ISO2631-relative standard directive.
Wide Adaptability
The crane can work in the environment between -30℃ and 50℃ and can be operated at the altitude less than 2000m as well as in the extreme windy areas (only after installing some optional parts).
Various Operating Conditions
The boom rated lifting capacity is 300t and the rated lifting moment is 1652Nm. There are seven operating conditions: H boom (20m~92m), combined boom (58m~100m), luffing jib (62m+66m), fixed jib (68m+42m), heavy fixed jib (74m+18m), combined boom + light fixed jib (88m+37m), and boom + luffing jib + light fixed jib (62m+60m+37m).
Safety and Reliability
Safe Control System
Switch between the operation and installation modes ensures the safety, and the crane's functions including real-time display of machine gravity and levelness, off-line stop, emergency electric control, lightning protection, and closed-circuit monitoring are highly convenient and reliable.
Electrical Control System
The fully electrically controlled system is adopted with fault self-diagnosis function. An electrical back up system is also equipped.
High Return & Low Cost
Optimized Design
The machine is designed according to the ANSI B30.5 EN13000 and GB3811 standards, with the transport dimension and weight complying with the domestic and international road transport regulations.
Self-assembly and Disassembly
The winch dragged by the clutch for easy reeving can remotely control the assembly and disassembly of basic machine, and the quick-change rope connectors and winch wire rope head can support the self-assembly and disassembly of the whole machine.
Centralized Lubrication
Automatic lubrication is provided by central lubrication system to key movement parts which substantially reduces maintenance time and workload. It takes no more than 30min/person for routine maintenance.
