Home > Products > Hydraulic water well drilling machine > Dth Drilling Machine Specification for Rock
Dth Drilling Machine Specification for Rock
- Qingdao/shanghai/tianjin/guangzhou
- T/T Credit Card
You May Like
-
High Speed Rock Bore Hole Drilling Machine
-
Deep Well Hammer Borehole Water Well Drilling Machine Prices
-
Strong Powerful Water Hole Drilling Machines
-
Portable Hydraulic Crawler Drilling Machine
-
Strong Hydraulic Bore Water Well Drilling Machine
-
High Speed 100m - 300m Air Compressor Water Well Drill Machine
Product Details
| Brand Name | TY | Place of Origin | Henan, China | |
| Model Number | TY260J | Certification | SGS | |
| After-sales Service Provided | Engineers available to service machinery overseas | Weight | 7800kg | |
| Dimension(L*W*H) | 6.1m*2.16m*2.65m | Voltage | 380V | |
| Condition | New | Power(W) | 65kw | |
| CNC or Not | Normal | Drilling Speed | 60M/HOUR |
Product Description
Product Application
water well DRILLING for farm irrigation, fresh water drinking, and any where need fresh water.
Main Features
1.Drills up to 200-300m deep, 250-350mm diameter, crawler mounted.
2. Can work with Air compressor OR Mud pump.
3. Fully hudraulic system, work with air compressor.
3. Drill fast in soft earth and in hard rock earth..
4. Mainly used for water well drilling,earth sample taking, mining exploration, rock falling fence, etc,
Machine Parts
Name: hydrualic Cylinder
Brand:YT
Original: China
Main Features
Name:DTH Hammer
Brand: YT
Original: China
DHD360
Machine Parts
Name: Drill rod
Brand: YT
Original: China
Diameter: 76mm,89mm,102mm
Length: 1.5m/3m
Main Features
Name: Air compressor
Brand:Zhigao
Original:China
Air consumption: 35m3/min
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
*Operating DVD, Mannual
*Quality Guarantee
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
* 24/7 service.
*2 years warranty
100m DTH Small drill rig
91.8% Response Rate
130m DTH small drill rig
91.8% Response Rate
300-400m DTH water well drill rig
91.8% Response Rate
600m core water well/exploration rig
91.8% Response Rate
150m mimi DTH water well drill rig
91.8% Response Rate
300-400m DTH water well rig
91.8% Response Rate
1.All spare parts can be changed for free with in 12 months.
2.The machine are expected to be functioning 10years with ability of spare parts.
3.You can enjoy technical support by phone call or email forever.We will respond quickly to provide a prompt solution.
4.On-site training could be executed if this term is included in the contracts agreed.
5.We can assign our engineers abroad for on-site service if this term is included in the contracts agreed
