JZH-101 Wireless Temperature and Humidity Sensor
- SHENZHEN
- T/T Credit Card
You May Like
-
JZH-102 Wireless Indoor Air quality CO2 VOC detector monitor
-
JRFW-2-22 Wireless Temperature and Humidity Sensor
-
IAQ CO2 gas detector with temperature and humidity
-
AT-2CO2 IAQ indoor air quality detector with temperature and humidity wall mounted wifi co2 detector
-
EA012 portable multi-gas detector
-
EA012 portable multiple harmful gases detector CO2 analyzer
Product Details
Brand Name | KUNLUN | Place of Origin | Shaanxi, China | |
Model Number | JZH-101 |
Product Description
Brief introduction
Collection, transmission integrated design, ultra-low power , intelligent management, intelligent transport . Transmission distance, the use of wireless 2.4G zigbee protocol , anti-interference ability. 16 physical channel selectable, 65535 Network ID can be set, networking ability. Suitable for indoor environmental measurement , agricultural greenhouses intelligent management.
Features
Large LCD screen displays the current information
Comply with 2.4GHz zigbee protocol
Ultra-low -power design , long product life
Measurement accuracy, anti-interference ability
The large number of network nodes , transmission distance
Technical parameter
Power supply | DC 12V (9V ~ 28V) or batteries ( lithium-ion battery 3.6V) |
Working frequency | 2.4GHz |
networks | ZigBee PRO protocol |
Communication distance | ≥800m ( open environment ) |
Channel | 16(0~0F) |
Network ID | 0x0000—0xFFFE |
Baud rate | 38400bps |
Range | Humidity: 0%RH~100%RH |
Accuracy | Humidity:±3%RH(5%RH~95%RH,25°C) |
Long-term stability | Humidity:1%RH/y |
Data transfer format | Initiative to report |
Work Environment | -20°C~60°C;5%RH~95%RH(Non-condensing) |
Storage Conditions | -20°C~60°C;5%RH~95%RH(Non-condensing) |
Power consumption
| Maximum 160mA(Send the instant ) |
The response time | 15s(1m/s wind speed) |
Battery life | One year (1 times/min, 25 °C + / - 5 °C, power 19 ah) |
Outer shell | ABS white 53 mm x 180 mm x 130 mm (not including antenna part) |
Working time | 1s |
Start-up time | ≤1s |
Sleep time | Set the range of 60 ~ 65535 s (the default 60 s) |
Installation | Using the wall mounting |
