XH-800US intelligent ultrasonication cell disruption

XH-800US intelligent ultrasonication cell disruption

Introduction

The instrument abandon the traditional ultrasonic cell disrupter power and probe split , power bulky defects , the use of integrated circuit control system, greatly reducing the volume of the instrument . The power of the probe , and operating system integration. Transducer probe with automatic lift, ultrasonic frequency automatic tracking , automatic temperature display.

Product Features

Instrument uses a single chip control technology and phase-locked loop frequency automatic tracking technology, through simple keyboard operation to set the data and control of the state . Power setting and temperature measurement circuit enables MCU ultrasonic transmitter power and over-temperature protection and alarm functions . And according to the viscosity of the reactants , the temperature difference , through automatic frequency tracking automatically to achieve the best sonic result . The instrument to achieve a portable machine functions. Probes for the import of titanium alloy material , durable, and are equipped with 8mm, 18mm horn . Temperature inside the box with PTFE coating processing technology, every speaker can effectively reduce the work during the noise , reduce the experimenter interference.

Technical parameters

1. Ultrasonic power: 0 ~ 1500 w continuous adjustable.

2. The ultrasonic frequency: 25 KHZ frequency automatic tracking, with automatic sweep frequency lock function.

3. High precision temperature sensor, the real-time monitoring system of temperature, temperature measuring range: 0 ~ 100 °C; Temperature measuring accuracy: 1 ‰

4. Work time: the biggest setup time is 100 hours, can be in this range any set work time.

5. The ultrasonic amplitude titanium alloy rod diameter: 8 mm, 18 mm is suitable for different diameter of the container.

6. Crushing capacity: 10 ml to 1000 ml

7. Working mode: ultrasonic pulse work arbitrary adjustable. With more than set temperature protection automatic ultrasonic work mode.
