High Efficiency 5kv Copper Conductor Submersible ESP Cable From China Cable Manufacturer
- Tianjin Qingdao or other main port
 - T/T Credit Card

You May Like
-


ESP Power Cable Copper Conductor PP Insulated and NBR Sheathed,galvanized Steel Tape Interlocked 13mm2 20mm2 33mm2 42mm2
 -


ESP Cable Solutions Rubber Insulation Lead Sheath Galvanized Steel Tape Armoured Type
 -


ESP Cable and Equipment Copper Conductor PP Insulated and NBR Sheathed,galvanized Steel Tape Interlocked 13mm2 20mm2 33mm2 42mm2
 -


3kv 5kv Rubber Insulation and Sheath Steel Tape Armored High Performance ESP Cable
 -


Copper Conductor PP Insulated and NBR Sheathed,galvanized Steel Tape Interlocked 13mm2 20mm2 33mm2 42mm2 ESP System Cable
 -


ESP Cable Suppliers and Manufacturers EPR Insulated and NBR Sheathed,galvanized Steel Tape Interlocked 33mm2 42mm2

Product Details
| Brand Name | RNEDA | Place of Origin | Hebei, China | |
| Model Number | ESP cable | Type | Medium Voltage | |
| Insulation Material | Rubber | |||
| Jacket | Rubber | Conductor Material | Copper |
Product Description
Conductor: Solid, bare copper per ASTM B3
Insulation: • The insulation is a specially compounded, oil resistant EPDM rubber with proven electrical properties
Jacket: • An oil resistant nitrile jacket is used to protect insulation and provide protection due to gas, heat and pressure
Barrier: • Bedding tape to protect the jacket. Rubber infused/ woven fabric
Armor: • Interlock profile, corrosion resistant galvanized steel. Double armor may be supplied where extra protection is required Option: • Stainless steel armor for increased protection in wells high in H2S and CO2 • Monel armor for maximum protection in wells extremely high in H2S and CO2
Industry references:
Industry standard:
• IEEE 1018
• API RP 11S6
• ASTM A459
• ASTM B3
• ASTM D412
Parameters:
6KV Type
AWG No.  | Cross-section (Approximation) mm2  | Conductor No./diameter mm  | Insulation Thickness mm  | Sheath Thickness mm  | Overall Dimensions mm×mm  | Reference weight kg/km  |
1  | 3×42.4  | 1/7.35  | 2.3  | 1.0  | 16×47  | 3850  |
2  | 3×33.6  | 1/6.54  | 2.3  | 1.0  | 15×45  | 3320  |
4  | 3×21.1  | 1/5.19  | 2.3  | 1.0  | 14×40  | 2730  |
5  | 3×16.8  | 1/4.62  | 2.3  | 1.0  | 13×38  | 2410  |
6  | 3×13.3  | 1/4.12  | 2.3  | 1.0  | 12×36  | 2100  |
7  | 3×10.6  | 1/3.60  | 2.3  | 1.0  | 11×34  | 1790
  |
We are one of China top rank cable&wire manufacturer.Our products meet standards of GB, IEC DIN ASTM, JIS, NF, AS/NZS CSA GOST and so on. We also have obtained ISO9001,ISO14001,OHSAS18001, UL,CE,
KEMA, TUV, SABS,PBS,Bureau Veritas, Lloyd,GL,NK,KR certifications.
We have obtained UL certifications for TC cable, DLO cable,RHH/RHW/RHW-2,XHHW/XHHW-2/SIS, THHN,SER/SEU/USE, MV-90/MV-105,MC cable,AC cable,TECK 90,SOOW,Welding cable,Mining cable,type DG,PV cable, Shipboard cable ESP Cable and so on.


CNAS accredited national level laboratory.
(1).When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please
call us or tell us in your e-mail so that we will regard your inquiry priority.
(2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight
charge should be paid.
(3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 1-2
days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account orprepay us if you do not have an account.
(4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is
delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
