Home > Products > ESP/SUBMERSIBLE OIL PUMP CABLES > ESP,Polyimide-F46 Composite File and EPR Insulated,EPR Sheathed,Galvanized Steel Tape Interlocked Armoring,Cable 200
ESP,Polyimide-F46 Composite File and EPR Insulated,EPR Sheathed,Galvanized Steel Tape Interlocked Armoring,Cable 200
- Tianjin Qingdao Shanghai or other main port
- T/T Credit Card
You May Like
-
1.8/3KV 4 AWG PVC Submersible Oil Pump Steel Armored ESP Cable
-
Oil/heat Resistant, Xlpe/EPR Insulated, 3 Core 5kv Submersible Deep Well Pump Cable
-
20mm2 Round ESP Power Cable, 3 Core PP Insulated and NBR Sheathed, Galvanized Steel Tape Interlocked Armoring Round Cable
-
China Supplier 42mm2 ESP Power Cable, 3 Core EPR Insulated and NBR Sheathed Submersible Oil/water/well Cable
-
20mm2 Round ESP Power Cable, 3 Core EPR Insulated and NBR Sheathed, Galvanized Steel Tape Interlocked Armoring Round Cable
-
Hot Sell 3.6/6kv 16mm2 Water Resistant PP/EPR Insulated Submersible Oil/water/well Pump Power Cable With Best Price
Product Details
| Brand Name | RNEDA | Place of Origin | Hebei, China | |
| Model Number | QYAQF10 | |||
| Conductor Material | Copper |
Product Description
ESP,Polyimide-F46 Composite File and EPR Insulated,EPR Sheathed,Galvanized Steel Tape Interlocked Armoring,Cable 200
Implemented Standard: Enterprise standard
Product Introduction
The product manufactured by us has the characteristics of advanced technology, reliable quality.
The main manufacturing equipment is included the ROYLE90 plastic extrude, the rubber continuous
vulcanizing process, the interlocked armoring machine made by CEECO, Canada, the continuous
sintering process imported from GRILLER, Austria, the Nokia cross
linked cable process, the
advanced continuous annealing process and tinned process, etc. Now, the cable and coil end lead
wire for submersible oil pump or pump unit can be produced, with different types and specifications,
the cross-section of conductor is 42mm2 and below. The well temperature is from 50℃ to 180℃, the max.
continuous working temperature of conductor is 204℃. The insulation material that can be used
is as below: PP, EPR, polyimide F46, fluoroscopic, XLPE, etc. The material of inner jacket includes NBR, compound of the neoprene and PVC, EPR,
fluoroplastics, lea, etc. The outer sheath material is as the galvanized steel tape, stainless steel tape, etc. All kinds of
cables for submersible oil pump can be developed according to the customer’s requirements.
HeBei huatong wires&cables Group Co.,ltd.It was established in 1993, we are JV with Furukawa(Japanese company) for rubber serious cables and JV with Riken(Japanese company) for elevator cables. Besides these,our submersible oil pump cable and shipboard cable are very influential in domestic, and, the traditional cables are also produced such as PVC powercables, XLPE power cables, ABC cables, wires, control cables, screened cables,communication cables, conductors.We areOEM for many USA, Europen, Australia cable company,70% of our products are exported, most customers are from developed countries. We got ISO,UL,TUV,KEMA,CE and many other certifications.
We are one of China top rank cable&wire manufacturer.Our products meet standards of GB, IEC
DIN ASTM, JIS, NF, AS/NZS CSA GOST and so on. At thte same time, we have obtained
ISO9001,ISO14001,OHSAS18001, UL,CE,KEMA, TUV, Bureau Veritas, Lloyd,IEC,GL,SA,NK,KR
certificates.
(1).When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your e-mail so that we will regard your inquiry priority.
(2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.
(3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account orprepay us if you do not have an account.
(4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
