Home > Products > Stainless Products > Stainless Steel Tube
Stainless Steel Tube
- Tianjin Port
- T/T Credit Card
You May Like
Product Details
| Brand Name | APEX | Place of Origin | Tianjin, China | |
| Model Number | round/sqaure/rectangular/Slot /Oval ETC | Certification | ISO | |
| Thickness | 0.4mm - 8mm | Type | Welded | |
| Application | decorations,construction and industry materials | Standard | ASTM, AISI, GB, JIS | |
| Outer Diameter | 10mm - 219mm | Welding Line Type | ERW | |
| Steel Grade | 300 Series |
Product Description
Stainless Steel Tube
1,standard:ASTM GB BS DIN
2.material:TP304 TO304L TP310/S TP316 TP316L
3.Thickness:0.5-20mm
4.outer diameter:5-300mm
5.package:seaworthy wooden case or as per the buyers' requirement
6.Application:mainly used in the field of liquid and gas transportation or construction or machine.
Name | stainless steel tube | |||||
| Standard | ASTMA249,A268, A269,A270, A312,A554,A688,A789,EN10217-7,EN10312,JIS G3468 | |||||
| Material Grade | TP304,TP304L,TP316,TP316L,TP317L,TP310S,TP321,AISI904L, AISI409L,AISI436L,AISI439,S31803/2205.etc. | |||||
| Outer Diameter | 10.0mm--219.0mm, other size is availiable. | |||||
| Thickness | 0.4mm - 8.0mm | |||||
| Length | 2000mm-9000mm or as customers' request | |||||
| Tolerance | a) Outer Diameter: +/- 0.1mm or as the standard. | |||||
| b) Thickness: +/- 0.02mm,or as the standard. | ||||||
| c) Length: +/-2mm,or as the standard. | ||||||
| Surface | Finished A+P and BA. | |||||
| Polishing,180#,240#,400#,600# Grit. | ||||||
| Hair Line | ||||||
| Application | Vessel, petroleum and chemical, light industry and food industry, pulp and paper industry, energy and environmental industries,etc | |||||
| Test | Hardness test(HRB), Flattening test,Flaring test,Flange Test, Reverse-bend Test, NDE,Hydro test,Inergranular Corrosion Test. | |||||
| Chemical Composition of Material | Material | 304 | 304L | 310S | 316L | 439 |
| Composition | ||||||
| C | ≤0.08 | ≤0.035 | ≤0.08 | ≤0.035 | ≤0.07 | |
| Si | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | ≤1.00 | |
| Mn | ≤2.00 | ≤2.00 | ≤2.00 | ≤2.00 | ≤1.00 | |
| P | ≤0.045 | ≤0.045 | ≤0.045 | ≤0.045 | ≤0.040 | |
| S | ≤0.030 | ≤0.030 | ≤0.030 | ≤0.030 | ≤0.030 | |
| Cr | 18.0-20.0 | 18.0-20.0 | 24.0-26.0 | 16.0-18.0 | 17.0-19.0 | |
| Ni | 8.0-11 | 8.0-13.0 | 19.0-22.0 | 10.0-14.0 | ≤0.05 | |
| N | ≤0.04 | |||||
| Mo | ≤0.75 | 2.0-3.0 | ||||
| Ti | Ti≥0.20+4(C+N);≤1.10Al≤0.15 | |||||
| Mechanical Property | Material Item | 304 | 310S | 316L | 439 | |
| Tensile Strength | ≥515 | ≥515 | ≥485 | ≥415 | ||
| Yield Strength | ≥205 | ≥205 | ≥170 | ≥205 | ||
| Extension | ≥40% | ≥40% | ≥40% | ≥20% | ||
| Hardness (HRB) | ≤90 | ≤90 | ≤90 | ≤89 | ||
| Payment | 30% T/T prepay +70% T/T against copy of B/L or 70% irrevocable L/C at sight. 100% irrevocable L/C at sight from top bank with more than 20000 dollars | |||||
| Delivery time | within 7 days if stock goods. | |||||
| within 30 days for custom made material. | ||||||
| Validity | 3 days | |||||
