galvanised h beam factory
- Tianjin Xingang Port
- T/T Credit Card
You May Like
-
Hot Rolled Steel Structure H Beam For Building
-
China price Q195 / Q235 / Q345 steel u channel purlin u channel galvanized u purlins
-
Customized u purlin size according to drawings for sale
-
Factory supply building materials metal structure u shape purlin
-
Good quality sale building materials u type channel steel purlin
-
Good sale black/galvanized surface u type channel steel purlin
Product Details
| Brand Name | Lanchuang | Place of Origin | Hebei, China | |
| Model Number | H100-900 | Length | 6-12m | |
| Thickness | 5.0mm-16.0mm | Application | Structure Construction | |
| Standard | JIS | |||
| Web Thickness | 5.0-16.0mm | |||
| Web Width | 100-900mm | Flange Thickness | 7-28mm | |
| Flange Width | 50-300mm |
Product Description
| | H=100~900mm |
| B=50~300mm | |
| tw=5.0~16.0mm | |
| tf=7.0~28.0mm | |
Meterial: Q235(equivalent to A36, SS400, S235JR, ST37-2) Q345(equivalent to S355JR, ST52-3) | |
Surface: black, galvanized or customized. |
GB STANDARD H BEAM:
| SIZE (mm) | KG/M | SIZE (mm) | KG/M | SIZE (mm) | KG/M | SIZE (mm) | KG/M |
| 100*50*5.0*7 | 9.54 | 248*124*5.0*8 | 25.8 | 390*300*10.0*16 | 107 | 498*432*45.0*70 | 605 |
| 100*100*6.0*8 | 17.2 | 250*125*6.0*9 | 29.7 | 394*398*11.0*18 | 147 | 500*200*10.0*16 | 89.6 |
| 125*50*6.0*8 | 13.3 | 250*250*9.0*14 | 72.4 | 396*199*7.0*11 | 56.7 | 506*201*11.0*19 | 103 |
| 125*125*6.5*9 | 23.8 | 250*255*14.0*14 | 82.2 | 400*200*8.0*13 | 66 | 582*300*12.0*17 | 137 |
| 148*100*6.0*9 | 21.4 | 294*200*8.0*12 | 57.3 | 400*400*13.0*21 | 172 | 588*300*12.0*20 | 151 |
| 150*75*5.0*7 | 14.3 | 294*302*12.0*12 | 85 | 400*408*21.0*21 | 197 | 594*302*14.0*23 | 175 |
| 150*150*7.0*10 | 31.9 | 298*149*5.5*8 | 32.6 | 414*405*18.0*28 | 233 | 596*199*10.0*15 | 95.1 |
| 175*90*5.0*8 | 18.2 | 300*150*6.5*9 | 37.3 | 428*407*20.0*35 | 284 | 600*200*11.0*17 | 106 |
| 175*175*7.5*11 | 40.4 | 300*300*10.0*15 | 94.5 | 440*300*11.0*18 | 124 | 606*201*12.0*20 | 120 |
| 194*150*6.0*9 | 31.2 | 300*305*15.0*15 | 106 | 446*199*8.0*12 | 66.7 | 692*300*13.0*20 | 166 |
| 198*99*4.5*7 | 18.5 | 340*250*9.0*14 | 79.7 | 450*200*9.0*14 | 76.5 | 700*300*13.0*24 | 185 |
| 200*100*5.5*8 | 21.7 | 344*348*10.0*16 | 115 | 458*417*30.0*50 | 415 | 792*300*14.0*22 | 191 |
| 200*200*8.0*12 | 50.5 | 346*174*6.0*9 | 41.8 | 482*300*11.0*15 | 115 | 800*300*14.0*26 | 210 |
| 200*204*12.0*12 | 56.7 | 350*175*7.0*11 | 50 | 488*300*11.0*18 | 129 | 890*299*15.0*23 | 213 |
| 244*175*7.0*11 | 44.1 | 350*350*12.0*19 | 137 | 496*199*9.0*14 | 79.5 | 900*300*16.0*28 | 243 |
Q1: What products can you offer?
We can provide cold bending steel purlins, thin iron wire, black steel tube, gi tube, gi/ppgi coil
and sheet, etc.
Q2:Why should I choose you?
(1) Contact us with your detailed inquiry, you will be replied within 24 hours.
(2)You are promised to obtain the best quality, price and service.
(3) We'd like to provide samples for your confirm.
(4) Wide excellent experiences with after-sale service.
(5)Every process will be checked by responsible QC which insures every product's quality.
Q3: Can you provide samples for checking before order?
Yes.Free samples with freight collect will prepared as required.
Q4: Can you accept customization?
Yes. If you have special requirements on products or packages, we can do customization for you.
Q5: What is the price term?
FOB, CIF, CFR, EXW are acceptable.
Q6: What’s the payment term?
T/T, L/C, D/A, D/P or other method as agreed.
