Home > Products > Channel Steel > Profile Structural U Shape Steel
Profile Structural U Shape Steel
- Xingang/Tianjin port
- T/T Credit Card
You May Like
-
U Channel Steel Iron Bar Standard Size 150x75mm Price
-
U Channel Steel Sizes/JIS Standard Hot Rolled 100*50*5.0 mm U Channel Steel Price
-
Ss400 Hot Rolled u Channel Steel Sizes
-
SS400 Q235 Hot Rolled Channel Steel Bar Price/u Channel Steel
-
Hot Rolled High Strength Universal u Shaped Hat Channel Steel Bar
-
Prime Quality Hot Rolled Q235 Grade Steel U Channel
Product Details
| Place of Origin | Hebei, China | Model Number | 5#-40# | |
| Shape | U Channel | Application | Building | |
| Standard | ASTM, GB, JIS | Grade | Q235 | |
| Dimensions | 50*37*4.5mm-400*104*14.5mm | Perforated Or Not | Not Perforated |
Product Description
Hot rolled steel U channel
Product: | Steel U Channel | ||
Standard / Grade: | GB / Q235 JIS / SS400 | ||
Length: | 6m / 12m | ||
Application: | Building structure Civil construction Mechanical manufacture | ||
Advantages: | Tolerance is made to order | ||
Payment terms: | T/T or L/C at sight | ||
Package: | Bundles | ||
| |||
GB standard | JIS standard | ||
Size | Theoretical weight (kg/m) | Size | Theoretical weight (kg/m) |
50*25*3.0 | 2.37 | 50*37*4.5 | 5.438 |
50*25*5.0 | 3.46 | 63*40*4.8 | 6.634 |
75*40*3.8 | 5.30 | 80*43*5.0 | 8.046 |
75*40*5.0 | 6.92 | 100*48*5.3 | 10.007 |
100*50*3.8 | 7.30 | 120*53*5.5 | 12.059 |
100*50*4.5 | 8.97 | 140*58*6.0 | 14.535 |
100*50*5.0 | 9.36 | 140*60*8.0 | 16.733 |
125*65*5.2 | 11.66 | 160*63*6.5 | 17.24 |
125*65*5.5 | 12.91 | 180*68*7.0 | 20.174 |
125*65*6.0 | 13.40 | 180*70*9.0 | 23 |
150*75*5.5 | 14.66 | 200*73*7.0 | 22.637 |
150*75*6.5 | 18.60 | 200*75*9.0 | 25.777 |
|
| 220*77*7.0 | 24.999 |
|
| 220*79*9.0 | 28.453 |
