Foam Concrete Pump Water Cement Sand Mixing Machine
- Shanghai/Qingdao/Tianjin
 - T/T Credit Card

You May Like
-


Foam Concrete Pump Cement Sand Feeding Machine
 -


Large Capacity Lightweight Concrete Pump Foam Generator for Foam Concrete
 -


Cellular Concrete Foam Small Foam Generator for Concrete
 -


Cellular Concrete Generator Pump Foam Concrete Cement Foaming Machine
 -


Cellular Foam Concrete Pump Portable Foam Generator for Concrete
 -


Small Foam Concrete Foam Generator for CLC Block Production Line

Product Details
| Brand Name | Keming | Place of Origin | Henan, China | |
| Model Number | KFP-32 Foam Concrete Pump | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
KFP-32 Foam Concrete Pump
Foam Concrete Pump Water Cement Sand Mixing Machine
Features:
1.KFP-32 Cement Foaming Machine combines feeding machine, water adding device, mixing system, foaming system, delivery system together. It is convenient to operate, automatic cement feeding, automatic mixing of cement slurry, automatic foaming of foaming agent, automatic delivery of foaming concrete.
2.The machine adopts high pressure foaming technology with good foaming performance,even,high quality,unbreakable,accurate(foaming amount can be precisely controlled within mg).
3.Delivery system adopts the most advanced pumping system of hose pump, with simple operation, low fault rate, less wearable parts, convenient maintenance,and low cost.
4.The machine shell is made of high strength and precious steel plate,which is painted at high temperature of 280℃ and has long service life.
5.The machine saves production costs and improves economical returns.Compared with similar products, the machine can save 50~100kg cement per cubic meter product.
6.The machine is the ideal equipment of foaming cement,with light weight,small size, convenient movement, high efficiency.
Application:
1.Take cement and coal ash as raw material to make foam concrete.
2.Insulating layer, bedding course, floor heating, filling projects of foam concrete roofing.
3.Other products of foam concrete.
Technical Parameters:
Items  | Unit  | KFP-32 foam concrete pump  |
Rated voltage  | V  | 380  |
Main motor  | KW  | 5  |
Output  | m3/h  | 3~5  |
Vertical delivery dist.  | m  | 60  |
Horizontal delivery dist.  | m  | 200  |
Particle size  | mm  | ≤5  |
Max. air pressure  | Mpa  | 1.0  |
Output pressure  | Mpa  | 1.0  |
Dimensions (length*width*height)  | mm  | 1300*700*1200  |
Main machine weight  | Kg  | 300  |
  |








Henan Coal Scientific Research Institute Co., Ltd. was established in March 1979. In 1999, it was ranked among the first batch of 242 coal research institutes, and implemented localized management by Henan Province. In 2006, it was transformed successfully into a scientific and technological enterprise, and renamed officially as Henan Coal Scientific Research Institute Co., Ltd.
Achievements: As one of the standard setting unit of national shotcrete equipment industry, the company has obtained more than 170 research and development achievements, more than 110 technical consulting services, 82 technology awards and15 national invention patents and utility model patents.
Application: mining well project, hydropower engineering, highway (railway) tunnel, subway engineering, bridge and slope maintenance, air-raid shelter construction, municipal construction, environmental greening project, blast-furnace refractories spraying, etc.
Main Products: wet/dry shotcrete machine, concrete/shotcrete pump, grouting pump, cement pump, mortar pump, slurry pump, hose pump, cement/concrete mixer, concrete foaming machine, plastering machine etc.
1.Q: Which model should we choose?
A: Many models are provided for your choice. Before suitable model is recommended, please tell us the application, materials, output and pressure you want.
2. Q: Can we have customized model?
A: Yes. Customized model is available according to your actual requirements.
3. Q: Do i need technical skills to operate this machine?
A: Yes. Please read the Operation Instruction for some basic technical skills.
And, we provide online and onsite technical training if necessary.
4.Q: What should we do if there are some problems with the machine?
A: You can refer to the Operate Instruction or call our 24-hour service hotline.
Also, our engineers are available to service overseas.
5.Q: What is the lead time?
A: 1 week for sample model, 2~3 weeks for customized model. It depends for mass production.
6.Q: How about the package?
A: We have fumigation-free wooden case to protect the machine from damage during the long-distance delivery.
7.Q: How to place an order?
A: Both pnline order and offline order are acceptable.
It is suggested to place online order with a Trade Assurance to get full protection for this order.
8.Q :How to pay for this order?
A: Generally, TT, 30% deposit 70% before shipment;
L/C at sight (high bank charge, not suggest, but acceptable);
100% TT in advance (especially for small amount and spare parts etc.)
