Super Quality High Pressure Washer Ceramic Triplex Piston Pump

FOB Price

US$ 70 - 300 / Set

30 Sets(Min. Order)

Port Ningbo
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	BOTUO	Place of Origin	Zhejiang, China
Model Number	BML-18.15-Triplex Piston Pump
Fuel	Diesel
Usage	Water	Theory	Jet Pump
Standard or Nonstandard	Standard

Product Description

Super Quality High Pressure Washer Ceramic Triplex Piston Pump

Product Description

♦♦ Description of Triplex Piston Pump

Triplex Piston Pump is designed for varieties of high pressure cleaning applications. The construction of the pump has die-cast crankcase, forged brass head, the internal components include solid ceramic-coated plungers, tapered roller bearing, one-piece connecting rod, and stainless steel checking valves.
The pump has the options of gearbox , belt drive, or coupling drive with electric motor, or gasoline, diesel engine.

♦♦ Specification of Triplex Piston Pump

Item	Triplex Piston Pump
Model	BML-18.15-Triplex Piston Pump
Flow Rate	18.7 L/min (4.9 GPM)
Pressure	150 Bar (2175 PSI)
Power	7.5 HP (5.5KW)
Rotation Speed	1740 r.p.m
Hollow Shaft	24mm, 28mm Flange On
Solid Shaft	24 mm
Inlet Port	1/2"
Discharge Port	3/8"
Lubrication	Oil Bath
Oil Bath Lubrication	1450, 1750, 2800, 3400 RPM.
Warranty	1 Year
Application	High Pressure Cleaning, Fogging, Humidification, Odor Control

♦♦ Tech Para

Model	Flow Rate		Pressure		Power		Rotation	Plunger	Stroke
Model	L/min	GPM	bar	psi	hp	kw	rpm	mm	mm
BML10.12	9.3	2.5	120	1740	3	2.2	1740	15	10
BML10.16	9.3	2.5	160	2320	4	3	1740	15	10
BML 10.22	9.3	2.5	220	3190	5.5	4	1740	15	10
BML 12.11	13.4	3.5	110	1595	4	3	1740	18	10
BML 12.15	13.4	3.5	150	2175	5.5	4	1740	18	10
BML 12.20	13.4	3.5	200	2900	7.5	5.5	1740	18	10
BML18.11	18.7	4.9	110	1595	5.5	4	1740	18	14
BML 18.15	18.7	4.9	150	2175	7.5	5.5	1740	18	14
BML 18.20	18.7	4.9	200	2900	10	7.5	1740	18	14
Remark:	1. Max. Pressure 250 bar
	2. The Rotation speed has 4 versions, 1450, 1740, 2800, 3400 rpm
	3. Hollow Shaft, 19, 24, 28mm; Solid Shaft 24mm

♦♦ Feature of Triplex Piston Pump

Brass Manifold
Ceramic Coated Plunger
HP Seals
Aluminum Alloy Crankcase, Anti-Corrosion, Heat Dissipation
Forged Crankshaft, Hardened, Tempered Steel
Aluminum Alloy Connecting Rod
Connecting Flange Available

♦♦ Application of Triplex Piston Pump

This Triplex Piston Pump can be used in hot and cold pressure washers, engine driven pressure washers, pressure test equipment, industrial cleaning products, special duty applications.

Food processing
High Pressure Cleaning, Dust Suspension, Odor Control, Humidification
Pharmaceutical & chemical industries
Livestock, animal husbandry
Car, Truck, Vehicles Washing
High Pressure Sewer Jetting
Others

♦♦ Advantage & Benefits

1. Cost-Effective & Profitable
Compared to other overseas companies, our pricing is more competitive, while the pump quality is very stable, durable, it has been proved by our valued clients around the world, therefore, to make the deal with us will become a profitable & pleased cooperation.

2. Stability & Dependability
We grasp all the technology of this Triplex Piston Pumps, and we utilize the highest quality materials & components, which makes this pressure pump durable & reliable.

3. Superior Service & Support
The technical support & assistance is available anytime, the quick-response will be effected. We will also find the most economical way to the spare parts requests.

♦♦ Product

♦♦ Certificate

Packaging & Shipping

♦♦ Trade Details

MOQ	30 sets Triplex Piston Pump
Sample	Sample available, but charged
Port	Ningbo
Packaging	Standard Carton Box, Single In One Box
Payment	L/C at sight, T/T, Western Union
Delivery	Within 2-4 weeks after receipt of payment
Shippment	By air, by sea, by truck / train, express

Our Services

♦♦ Our Service

1. We have a strong team that can offer the best service for our customers.
2. Stable product quality, strict quality control.
3. Accredited entity, fast delivery.
4. Available 7x24 Technical Assistance & Support.
5. Reasonable replacement parts service.
