G Series Mono Screw Pump
- Ningbo/Shanghai
- T/T Credit Card
You May Like
Product Details
| Brand Name | Associated | Place of Origin | Zhejiang, China | |
| Model Number | G series | Application | Sewage | |
| Power | Hydraulic | |||
| Usage | Oil | Theory | Rotary Pump | |
| Standard or Nonstandard | Standard | Structure | Screw Pump | |
| Pressure | High Pressure |
Standard export carton/plywood case
Product Description
G series mono screw pump
1. The mono pump is sealed on the inside gearing, belong to rotor displacement pump
2. The essential part consists of combination of a stator with two-start female thread and a rotor in planetary motion by the universal coupling, between the stator and the rotor, being in mesh continually, the medium handled is transmitted to the outlet port from the inlet port
3. The liquid transmitted to get not confused or disruptive, thus it is most suitable for lifting mediums containing solid matter, abrasive particles and viscous liquids
4. Widely aplicable for food industry,metallurgy,paper making,printworks,chemical,fertilizer and pharmacy. Can be used as oil pump and sewage pump.
5. Very competitive price
6. 1 year of warranty
7. Short delivery time
Technical Specifications
Model | Speed | Flow | Pressure | Motor power | H (m) | Inlet | Outlet (mm) | Allowable particle diameter(mm) | Allowable fibre diameter(mm) |
G20-1 | 960 | 0.8 | 0.6 | 0.75 | 60 | 25 | 25 | 1.5 | 25 |
G25-1 | 960 | 2 | 0.6 | 1.5 | 60 | 32 | 25 | 2 | 30 |
G25-2 | 960 | 2 | 1.2 | 2.2 | 120 | 32 | 25 | 2 | 30 |
G30-1 | 960 | 5 | 0.6 | 2.2 | 60 | 50 | 40 | 2.5 | 35 |
G30-2 | 960 | 5 | 1.2 | 3 | 120 | 50 | 40 | 2.5 | 35 |
G35-1 | 960 | 8 | 0.6 | 3 | 60 | 65 | 50 | 3 | 40 |
G35-2 | 960 | 8 | 1.2 | 4 | 120 | 65 | 50 | 3 | 40 |
G40-1 | 960 | 12 | 0.6 | 4 | 60 | 80 | 65 | 3.8 | 45 |
G40-2 | 960 | 12 | 1.2 | 5.5 | 120 | 80 | 65 | 3.8 | 45 |
G50-1 | 960 | 20 | 0.6 | 5.5 | 60 | 100 | 80 | 5 | 50 |
G50-2 | 960 | 20 | 1.2 | 7.5 | 120 | 100 | 850 | 5 | 50 |
G60-1 | 960 | 30 | 0.6 | 11 | 60 | 125 | 100 | 6 | 60 |
G60-2 | 960 | 30 | 1.2 | 15 | 120 | 125 | 100 | 6 | 60 |
G70-1 | 720 | 45 | 0.6 | 11 | 60 | 150 | 125 | 8 | 70 |
G70-2 | 720 | 45 | 1.2 | 18.5 | 120 | 150 | 125 | 8 | 70 |
G85-1 | 720 | 65 | 0.6 | 15 | 60 | 150 | 150 | 10 | 80 |
G105-1 | 500 | 100 | 0.6 | 22 | 60 | 200 | 200 | 15 | 110 |
G135-1 | 400 | 150 | 0.6 | 37 | 60 | 250 | 250 | 20 | 150 |
Real photos bought by our importer and manufacturer India:
