YL Series 1.25hp Motor
US$ 20.1 - 200
/ Piece
50 Pieces(Min. Order)
- FUZHOU
- T/T Credit Card
You May Like
Product Details
| Brand Name | OMEIK MOTOR | Place of Origin | Fujian, China | |
| Model Number | 1.25hp motor | Type | Asynchronous Motor | |
| Output Power | 0.25KW | Frequency | 50HZ OR 60HZ | |
| Efficiency | IE 1 | |||
| Certification | CCC, CE, ROHS | Phase | Single-phase | |
| Protect Feature | Totally Enclosed |
Product Description
YL series single phase induction motor Application:
1, YL Series Single phase dual-capacitor asynchronous motor is designed and manufactured in according with national standard.
2, newly developed by our company with low noise, compact dimension, light weight, easy maintenance, etc.
3, These motors are widely used on air compressors.pumps,fans, refrigeration, medical instruments, small-size machines, etc. especially for occasion where only single-phase power supply is available.
Overall & Installation Dimenstions
| Frame size | Mounting Dimensions | Overall | |||||||||||||||||||||||||
| IMB14. IMB34 | IMB5.IMB35 | Dimensions | |||||||||||||||||||||||||
| A | B | C | D | E | F | G | H | K | M | N | P | R | S | T | M | N | P | R | S | T | AB | AC | AD | AE | HD | L | |
| 71 | 112 | 90 | 45 | 14 | 30 | 5 | 11 | 71 | 7 | 85 | 70 | 105 | 0 | M6 | 2.5 | - | - | - | - | - | - | 145 | 145 | 140 | 105 | 180 | 255 |
| 80 | 125 | 100 | 50 | 19 | 40 | 6 | 15.5 | 80 | 10 | 100 | 80 | 120 | 0 | M6 | 2.5 | - | - | - | - | - | - | 160 | 165 | 150 | 120 | 200 | 295 |
| 90S | 140 | 100 | 56 | 24 | 50 | 8 | 20 | 90 | 10 | 115 | 95 | 140 | 0 | M8 | 3 | - | - | - | - | - | - | 180 | 185 | 160 | 130 | 240 | 370 |
| 90L | 140 | 125 | 56 | 24 | 50 | 8 | 20 | 90 | 10 | 115 | 95 | 140 | 0 | M8 | 3 | - | - | - | - | - | - | 180 | 185 | 160 | 130 | 240 | 400 |
| 100L | 160 | 140 | 63 | 28 | 60 | 8 | 24 | 100 | 12 | - | - | - | - | - | - | 215 | 180 | 250 | 0 | 15 | 4 | 205 | 220 | 180 | 130 | 260 | 430 |
| 112M | 190 | 140 | 70 | 28 | 60 | 8 | 24 | 112 | 12 | - | - | - | - | - | - | 215 | 180 | 250 | 0 | 15 | 4 | 245 | 250 | 190 | 140 | 300 | 455 |
| 132S | 216 | 140 | 89 | 38 | 80 | 10 | 33 | 132 | 12 | - | - | - | - | - | - | 215 | 180 | 300 | 0 | 15 | 4 | 280 | 290 | 210 | 155 | 350 | 525 |
Technical date at 50 Hz
| Model | Power | Voltage (V) | Current (A) | Speed (r.p.m) | Eff (%) | Power factor | Starting Torque Rated torque | Starting Current rated current | Max torque Rated torque | |
| KW | HP | |||||||||
| YL711-2 | 0.37 | 1/2 | 220 | 2.73 | 2880 | 67 | 0.92 | 1.8 | 16 | 1.8 |
| YL712-2 | 0.55 | 3/4 | 220 | 3.88 | 2880 | 70 | 0.92 | 1.8 | 21 | 1.8 |
| YL801-2 | 0.75 | 1 | 220 | 5.15 | 2800 | 72 | 0.92 | 1.8 | 29 | 1.8 |
| YL802-2 | 1.1 | 1.5 | 220 | 7.02 | 2800 | 75 | 0.95 | 1.8 | 40 | 1.8 |
| YL90S-2 | 1.5 | 2 | 220 | 9.44 | 2820 | 76 | 0.95 | 1.7 | 55 | 1.8 |
| YL90L-2 | 2.2 | 3 | 220 | 13.7 | 2820 | 77 | 0.95 | 1.7 | 80 | 1.8 |
| YL7114 | 0.25 | 1/3 | 220 | 1.99 | 1400 | 62 | 0.92 | 1.8 | 12 | 1.8 |
| YL7124 | 0.37 | 1/2 | 220 | 2.81 | 1400 | 65 | 0.92 | 1.8 | 16 | 1.8 |
| YL801-4 | 0.55 | 3/4 | 220 | 4 | 1400 | 68 | 0.92 | 1.8 | 21 | 1.8 |
| YL802-4 | 0.75 | 1 | 220 | 5.22 | 1400 | 71 | 0.92 | 1.8 | 29 | 1.8 |
| YL90S-4 | 1.1 | 1.5 | 220 | 7.21 | 1420 | 73 | 0.95 | 1.7 | 40 | 1.8 |
| YL90L-4 | 1.5 | 2 | 220 | 9.57 | 1420 | 75 | 0.95 | 1.7 | 55 | 1.8 |
| YL100L1-4 | 2.2 | 3 | 220 | 13.9 | 1420 | 76 | 0.95 | 1.7 | 80 | 1.8 |
| YL100L2-4 | 3 | 4 | 220 | 18.6 | 1420 | 77 | 0.95 | 1.7 | 110 | 1.8 |
| YL112M-4 | 2.2 | 3 | 220 | 13.9 | 1440 | 76 | 0.95 | 1.7 | 80 | 1.8 |
| YL112M1-4 | 3 | 4 | 220 | 18.6 | 1440 | 77 | 0.95 | 1.7 | 110 | 1.8 |
| YL112M2-4 | 4 | 5.5 | 220 | 23 | 1440 | 78 | 0.95 | 1.7 | 138 | 1.8 |
| YL132SA-4 | 3 | 4 | 220 | 18.6 | 1440 | 77 | 0.95 | 1.7 | 110 | 1.8 |
| YL132SB-4 | 4 | 5.5 | 220 | 23 | 1440 | 78 | 0.95 | 1.7 | 138 | 1.8 |
Motor Sample Room:
Factory Views:
Motor Certificate:
