Double Volute Casing End Suction Pump for Dirty Water Transfer

  double volute casing end suction pump for dirty water transfer

1.Breif Introduction:

S (SH) High concentrations horizontal split case pump are late-model energy-saving horizontally split pumps newly developed by us on the base of the old style double suction pumps at home and abroad.They are used to handle clean water or other liquids similar to waterin physical and chemical dium temperature not exceeding 80°C.This series of pumps are applicable for water supply for factories,mining,urban water supply  and drainage,power stations, farmland irrigation and drainage,and soon.Shaft sealing is soft packing sealing.

2.Features

1:   Adopts horizontal, vertical axis medium open type double pump shell structure, lining for cemented carbide  or rubber has good wear-resisting, corrosion resistance and high reliability.

2:  High efficiency hard alloy, and low NPSH.

3:  to meet the different operation conditions, adopted the brief type structure bearing parts, selected high bearing capacity design, alloy bearing grease lubrication oil.

4:   through adjusting the clearance between protection board and impeller, ensuring the pump efficient operatio.

5:   using packing seal, impeller sealing , container type mechanical seal to adapt to different operating mode requiremen.

6:   Pump and drive can choose straight league transmission, triangle, hydraulic transmission device coupled transmission, reducer drive.

7:   the outflow direction can be installed by eight Angle rotation to adapt to different site installation condition.

8:   available to use multipole series, to satisfy the long-distance transmission requirements.

3.Construction drawing

4.Peformance Curves Chart

5.ParameterTable

6.Deatail Photoes

7.Packing&shipping:

Why always me, because we do pump right!!!

20years experience of manufacture with 5years oversea service.                >>Advanced equipment with qualified engineers.

>> Large foundry to control excellent quality.

 8.MST at Expo:

                    High Quality,Good Service!

                      Welcome to contact us!
