355nm uv laser marking machine

FOB Price

US$ 14500 - 16500 / Set

1 Set(Min. Order)

Port SHANGHAI
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TINHO	Place of Origin	China
Model Number	THU05F	Certification	CE, GS, SGS
Condition	New	Power(W)	5
Graphic Format Supported	AI, BMP, DST, DWG, DXF, DXP, LAS, PLT	Control Software	WINDOWS
Cooling Mode	Water Cooling	CNC or Not	Yes
Laser Type	Diode	Working Accuracy	0.01MM

Product Description

Application Scope:

It can mark time, date, text, serial and part numbers, company logos, icon, symbol, bar codes, or 2D codes, matrix and vector fonts on all plain, painted, powder coated, anodized, or plated metal surfaces, whether they are flat sheets, curved surfaces, or cylinders.

Product Specification:

Type Item		Fly UV Laser Pinter
Laser machine features	Machine Body	Complete Aluminum Structure
	Laser Type	UV Laser
	Output Power	≥5W
	Laser Wave	355nm
	Scanning system	High precision double scanning system
	Marking Speed	≤12000mm/s
	Controller	13'' Color touch screen
	Operation System	Win CE
	Cooling System	Water Cooling
Laser printing parameters	focusing lens	Focus distance 200mm（Optional）
	Marking Line type	Dot-matrix, Vector font can be printing
	Min Line size	0.01mm
	Repeated positioning accuracy	0.003mm
	Marking Area	110mm×110mm（Optional）
	Positioning	Red light positioning and automatic focus
	Line Printing	Multi-line within marking size
	Production line Speed	0~180m/min (based on different materials)
Supported types	Font	English, logo, number, date, time, barcode etc...
	File format	PLT/CNF
	Barcode	CODE39、CODE128、CODE126、QR、
Machine Parameters	Power Supply	110-240V
	power consumption	1100W
	N.W	135KG
Suggest working environment		humidity≤80%; The condensation; No vibration
Suggest working environment		15-30℃

Application Industry:

Plastic Pipe & Cable	PVC Cables, PVC Pipes, PVC Profile
Beverage	PET Bottles, Glass Bottle(Wine Bottle),
Medicine Industry	Medicine Box(Original & Lamination), Capsule, Liquid Bottle etc
Food	Vacuum Bags, Plastic Bags
Art-Work	Woods
Porcelain	Dishes, Plate

Sample Show：

Product Features:

Laser oscillation in the fiber optical wave, low dissipation, good stability and is not affected by external dust gas and mechanical looseness, the output of a laser beam is stable.

Processing speed is 2 to 3 times the traditional laser marking machine.

Wind cooling fiber laser, no consumables, low maintenance, high photoelectric conversion rate, low consumption (500 w) or less, use cost.

Integrated design, small size (there are a whole cabinet and portable optional).

Environmental adaptation ability strong can be in vibration, shock, dust, humidity environment continuous work, easy to implement with optical fiber coupling, which can realize remote work.

Software running on WINDOWS platform, Chinese/English interface, can be compatible with AUTOCAD, CORELDRAW, PHOTOSHOP software, such as PLT, PCW, DXF, BMP, etc, but also can be used directly SHX, TTF font.

Bar code, QR code, graphics, text rules and irregular marking serial number, etc.
