Brief Description of 10L Glass Reactor

F-10L single layer glass reactor is a series product of single layer glass reactor, its max volume is 10L, max rotating speed can reach to 450rpm, its reaction bottle volume is 10L, that’s why it is known as F-10L single layer glass reactor, also called: glass vacuum reactor, extractor, multifunctional reactors, it can make various of solvent synthesis reaction under the condition of constant temperature. The reactor part is controllable sealed structure, which can use negative pressure continuous inhalation of various liquids and gases, and make reflux or distillation under different temperature.

Working principle of F-10L single layer glass reactor:It is through the oil bath pot (tank) into the constant temperature (high temperature or low temperature) heat solution or coolant to heat or cool the material in the reactor, and can provide stirring. The device can process vacuum stirring reaction, distillation condensation reaction, extraction and separation, and reaction heat experiment, we can through the water by condensing coil in the oil bath to achieve the effect of rapid cooling, material react in the reactor, and can control the reaction solution’s evaporation and reflux, after the reaction is completed, the materials can be released from reactor lid opening or the discharge port, the operation is very convenient. Our company absorb domestic and international advanced technology, launched the latest multipurpose products. It is convenient to use and beauty in appearance, affordable, and it is a ideal equipment for modern chemical, new material synthesis test.

Product features of F-10L 10L Glass Reactor:
1.Use GG17, G3.3 high borosilicate glass, owns excellent chemical and physical performance.
2.Applicable for conducting experiment under normal temperature, high temperature(200°C) and low temperature(-80°C) reaction condition.
3.Applicable for working under normal pressure or negative pressure, negative pressure can reach to -0.098MPa range in stationary state.
4.Digital display of stirring speed, imported high torque reinforcement electrical machine, frequency conversion constant temperature stirring system, stable working state.
5.PTFE stirring valve, sealing between stirring shaft and reactor is made from special material.
6.Large charging valve without any dead space, anti-corrosion, you can put both liquid and solid.
7.Thorough remove solution, no liquid remain.
8.Scientific overall structure, novel, practical and beauty in appearance.

If you are interested in this product, pls send me inquiry Contact Supplier

For more information, please contact us

Contact Supplier

Contact us

for more details about price, packing, shipping and discount.

Tel: 86-371-67447999

Web:

Address: Jianshe Road, Zhongyuan District, Zhengzhou,
Henan, China

Q: What’s the difference between vertical and inclined condenser?

A: They have no difference essentially. Vertical condenser is gradually popular because of its small space usage and convenience for transportation and use. Most high-capacity instruments use vertical condenser.

Q: What factor decides the working efficiency of  Electric Distillation Apparatus ?

A: For same type equipment, mainly includes: steam temperature, vacuum degree and cooling water temperature. Restricted by some material’s thermolability, the steam temperature may have certain limitation when working, so high vacuum degree and low cooling water temperature are two main factors for efficiency improving.

Q: How to select all kinds of  Electric Distillation Apparatus ?

A: As for structure, our R series products all have excellent corrosion resistance ability and leakproofness ability. According to the solvent volume, 2L, 3L, 5L’s machine is fit for lab and sample test; 5L, 10L, 20L’s machine is fit for medium experiment; 20L, 50L’s machine is fit for medium experiment and production, especially suitable for the extraction of metal ionavoiding polluted material.
