For the steel storage grain silo

1. Material : hot-galvanized steel sheets

2. Zinc coating : 275 g /m2

3.Bottom : two types:  Hopper bottom and Flat bottom

4. Volume :  around 1430 m3

5. Inside the grain silo body : we equip the Level system, Ventilation system,

Temperature control system.Draft fan .

6. Complete line includes :  Cleaning , Transport, Silo body, Electric control system, at site.

Packaging

Packaging:all machines covered by plastic film firstly and then packed in wooden case to best protect the machine during long time transportation.

shipping

Shipping: All machines will be sent by sea, if you need other kind of transportation, please inform us in advance. And all machines would be shipped in 7 days after the receipt of payment. Before and after shipping, we will take photos of machines and send photos to client.

Our service

1. One year quality warranty for the machine and spare parts

2. Overseas engineers service for installation

3. Whole-life after-sales service and free consultation

4. Customized requirements available

5. Technician guide at the site.

6. 24Hr online service

1.About us

Henan Institute Of Grain Machinery Manufacturing Co., Ltd. is established driven by the academy of Henan University of Technology. As a large joint-stock enterprise integrating technology, manufacture and sales, our company is specializing in the production of grain and oil machinery, agricultural and sideline machinery. Cooperating with Henan Mechanical Design and Research Institute and Henna University of Technology (Former Zhengzhou Grain College), Henan Institute Of Grain Machinery Manufacturing Co., Ltd. has carried out the research and application of oil machinery, food machinery, grain machinery, construction machinery, and feed machinery, etc.

we provide a turnkey project of our machinery,including special design,installation, commissioning and training workers.

2.Why choose us

---Advanced equipments,good quality

---Professional skills,all-related services

---High quality and efficiency technology

---Complete production line,quick delivery

---The biggest grain and oil machine manufacturer and exporter in China

---Exporting to more than 30 countries and regions

 1. What is the types of this assembly silo?

A. Hopper bottom: Steel cone base:

The capacity is below 800t and the diameter is below 8.5m.

B. Cement cone base / Flat bottom:

The capacity is comparatively big and the diameter is below 12m, its base is general made into  cement cone  base.

2.  what is the zinc coating per sqm available ?

The silo is made of hot-galvanized steel sheet 275g/m2,350 g/m2 and 400g/m2 are options.

3. What is the usage of the fabricated silo ?

The steel silos are widely used in grain storage, animal feed, flour, starch, rice milling   factory, grease processing, brewing, monosodium glutamate etc.
