Full automatic toothpick machine for wooden and bamboo toothpick making

duct introduction

Can use many different specifications woods, such as round log, square wood and

undersized wood. As well as the bamboo.we have one line process wood or bamboo to tooth pick or chopsticks.can introduce you best machine as customer request.

2. work efficiency

Usually one cubic meter can produce 100000 wooden toothpick of ¢ 2.2 X65MM

specifications. According to different press bubble wood and hardwood material,it is about 150 to 200 kilograms.

3. Production line

Raw bamboo saw -- bamboo dissection machine -- thickness and width slicer -- bamboo filament shaping machine -- bamboo filament set-size machine -- toothpick set-size machine -- rolling sharpen machine -- toothpick sorting machine -- toothpick mincing machine -- multisharpen machine

4.Product Description
1)Raw Bamboo Sawer
This machine is used to saw raw bamboo. Saw bit can saw the whole raw bamboo into required length. This machine has easy operationhigh efficiencyconvenient maintain and installment.
2)Bamboo sharpener
This machine is one of the making line of toothpickchopsticks and food peg wood. It is used to dissect the raw to inquired size. The width and thickness are about 60mm.
3)Fixing width Double sided Trimmer
This machine is one of bamboo toothpick making line. Its main function is to wipe off bamboo jointrefit bamboo brim and split layers. It applies to make required width and thickness of bamboo flake.
 4)Bamboo batten drawing machine
This machine is used to draw the slice to wirelike bamboo thread. The threads have the same width and thickness as the toothpick. This machine applies to make bamboo toothpick, food peg wood and so on.
5)Bamboo-wool ruler fixer
This machine applies to set size of wooden or bamboo thread. The length is about 260-300mm. After cutting the thread, the thread can be cutter into toothpick length by toothpick ruler fixer.
6)Toothpick ruler fixer
This machine is used to set size of wooden or bamboo thread. The length is about 65mm, just as the length of toothpick. It consists of fixed clampmotor saw bit and foundation bed. The fixed is installed in a removable frame.
7)Reciprocating Polishing machine
This machine applies round toothpick wood chopsticksbarbecue peg wood and other food peg wood.
The motor pull the hopper back and forth, and then sticks rub each other and become smooth.
8)Aligning machine
This machine is used to put the wood sticks in order. Put the polished wood sticks into the quadrate basket. The basket has many small quadrate grids; The length is the same as sticks. Start the motor, the basket move back and fro, then disorder sticks fall into grids because of inertia and become order.
9)Toothpick polishing machine
The machine is to process wooden and bamboo toothpick. It consists of hopperfeeding gear fixed geardischarging tankgrinding wheel, transmission system with belt and chain. Hopper inside has vibrating sliding plate and on-off board, make material feeding smoothly. It can sharpen one end or two ends of toothpick. This machine install dust absorption system, the dust is expelled automatically.
10)Blade sharper
Blade sharpener is specially designed for grinding carbide saws easily and efficiently. This blade sharpener machine can sharpen flat tooth, tilting tooth, alternate tooth, composite tooth of carbide saw blade and other saw bit.

About packaging, for small size or single machine, we can offer free fumigation wooden case with steel frame, it not only can protect machine from damage, but also avoid checking when exporting.

For multiple machines or production line, it's better to loaded in standard container 20GP, 40GP, 40HQ, unually it needs wrapped with plasitc firstly, then loaded in container.

we can offer EXW, FOB and CIF terms.

EXW: You arrange the shipping details from our factory to your port by yourself.

FOB: We arrange freight transport to Qingdao, Shanghai or other ports of China, then you arrange the shipping details from China port to your country port.

CIF: We arrange all shipping details to your country port, and ensure machines smooth arrival.

1. Help you choose the most suitable machine.
2. Making the machine according to your request.
3. Give you machine’s details and video for help you use the machine more better.
4. One year warranty
5. Quality problem,we will send you the accessories.
6. Free repair whole using life without extra charge.

KAIFENG RAINBOW MACHINERY Co.Ltd. is specialized in production of machines used in food, feed, farm and tech field. We have our own professional research and development department, and specialized production base.
Relying on the strong industrial and technological superiority and excellent transportation advantage, our company has had strategic development.
High quality is our obligation. Great service is our mission.We warmly welcome clients around the whole world to visit our plant and our Office!

5

*How do you guarantee I can receive the goods that ordered after make the payment?

Please rest assured that you will receive the goods in time, we are a legally established company supervised by the government, and is registered in customs of China and China Chamber of International Commerce. Besides, we are the golden member of Alibaba and has been checked by the third party as the real and legal company, what is more important, honesty and trustworthiness is our basic principle and our company life.

* How to make the payment?

Normally, when the order value is below USD10,000, we accept the payment by T/T or Western Union or Cash, L/C will be accepted when the order value is over USD10,000. For T/T, the customer can choose 100% in advance or 30% in advance, and pay the 70% balance before shipment.

*Date of delivery?

We will arrange the production and shipment as soon as possible when we received the deposit, and update the information with the customer on line.

*Suitablity of motor?

As there are many volatage standards in different countries in the world, so the original motor equipped on the machine would not suitable to be used with the customer's local power supply, when this situation happend, please send us your exact information of the power supply available, then we can modify the motor accordingly.

*After sale service?

For most of the machines, the quality is guaranteed for one year since the date of shipment expet wearing parts, we supply the on-line service for all the machines, and also supply the spare parts all the time with cost price, for some complicated machine or plant, we can send our engineer overseas too.
