Home > Products > Drying Equipment > Small Fruit Vacuum Freeze Drying Machine
Small Fruit Vacuum Freeze Drying Machine
- QINGDAO/SHENZHEN
- T/T Credit Card
You May Like
-
vegetable and fruit drying equipment/drying fruit oven/organic freeze dried fruit machine
-
low temperature vacuum drying machine to dry tea leaves
-
Low temperature fruit vacuum freeze drying machine with stainless steel made
-
Full-automatic continuous low-temperature Vacuum dryer
-
low temperature fruit and vegetable vacuum freeze drying machine / Industrial freeze dryer
-
Food/fruit Drying Machine
Product Details
| Brand Name | QUATE | Place of Origin | Henan, China | |
Product Description
Freeze Drying Machine
Characteristics of Mini Freeze Drying Machine:
1. Green environment-friendly product to conform to international standard
2. LCD display, Chinese, and English interface, drying curve being displayed;
3. the mouth of cold trap is big, no internal coil, having the function of precooling the samples
4. imported compressor with big capacity of refrigerating, and noise small;
5. Cold trap and Operation panel area all corrosion-resistant stainless steel, bright and
6. The organic glass cover can help you observe the whole freeze drying process.
7. Stainless steel sample shelf, the space of common sample tray can be adjusted.
Material Tray of Lab lyophilizer:
Common type: specially designed stainless steel sample shelf, the space of common sample tray can be adjusted, the amount of layers can be designed freely; the diameter of material tray is 200mm,amouting to 4 layer, the amount of the material on it is about 1000mL (the depth of the material 10 mm) .
Mini Freeze Drying Machine :
Name and Model | TOPT -10A Vacuum Freeze Dryer / Lyophilizer |
Freeze Drying Area | 0.03m2/layer |
Cold trap temperature | -55, (optional -80)°C |
Vacuum | <10 Pa |
Water-capture capacity | 3~4 Kg/24h |
Material tray | diameter 200 mm |
Tray number | 4 (optional 6) layer |
Whole power | 600 W |
Main frame size | 425*615*(370+445) mm |
Main frame weight | 40 Kg |
Liquid capacity | 1.2 L |
picture of machine:
- Stretch film inside and plywood case(non-fumigation woden package) outside is applied for machine,which is safe and to meet the international standard transport.
- Shipping by sea with container or by air is usual as your request.
Service before sale
1, 24 hours online .Your inquiry will be quick reply by email .
Also can go through all questions with you by any online chatting tools (Wechat ,Whatsapp ,Skype ,Viber ,QQ ,TradeManager )
2,Professionally and patiently introduction,details pictures and working video to show machine
Service on sale
1,Test every machine and inspect the machine seriously .
2,Send the machine picture which you order , then packing it with standard export wooden box after you confirm the machine is ok .
3,Delivery:If ship by sea .after delivery to seaport .Will tell you the shipping time and arrival time . Finally, send all original documents to you by Express For Free.
If delivery it by Express to your door(DHL, TNT,Fedex, etc) or by air to your airport, Or logistic to the warehouse which you request . We will tell you the tracking number after delivery.
Service after sale
1, Free insurance for goods
2, 24 hours online to solve any problem . Supply you English manual book and technical support , maintain and install video to help you solve the problem, or dispatch worker to your factory.
- We are professional manufacturer and suppiler for food machines.
- Competitive price with high quality machine will be provided according to your request.
- Please feel free to contact me for any question about food machine.
- You will be happy with our quick and satisfactory reply.
