High Efficient Fish Flour/meal Production Machine Fish Meal Processing Equipment

 Introduction of fish meal processing equipment:

This fish meal processing equipment is specially design and manufacture for customers who want to make fish meal, meal flour by using leftovers like fish head, fish sausages and offals, also can deal with small whole fresh fish, the whole production line has a compact structure, good-looking appearance, easy operate and good performance.

Feature of fish meal processing equipment:

1.Stainless steel with reasonable design and high automation.

2.Process:Screw conveyor----Cooking----Pressing----Drying----Packing.

3.The raw material can be whole fish, different kinds of fresh fish, shrimp, loach, fish heads, fish sausages

Wide application of fish meal processing equipment:

Raw materials: Whole fish, different kinds of fresh fish, fish heads, fish sausages and offals.

This line can be used to produce nutritional fish meal, it is high quality feed for different kinds animal such as dog, cat, cattle, fish, duck, chicken, the final meal can be easy digestion, nutrition will be 90% better absorbed.

The Fish meal Processing Line is as below:

1. Fish meal Processing Line  consists of Cooking-Pressing-Decanting-       Drying-Cooling-Grindering and Packing;

2.The fish passes through a electrical magnet to remove iron like fish          hooks.The raw material is cooked  in a steam cooker where the

   protein of the mass is coagulated, the fish oil is liberated.The mass

   from the cooker goes to twim screw press to squeeze out as much

   liquid as possible from the solid phase.

3.After pressing, we get press cake and press liquor.The sludge

  is recovered in a decanter and then dryed in dryer after mixed with

  press cake.The liquid after decanter is treated in a oil separator.

  In the high speed centrifuge, fish oil is separated. the stickwater goes

  to evaporator.

4. The stickwater is good for fishmeal,in  Fishmeal Processing Line  ,

    the stickwater after evaporator,its concentrate continously by the           waste vapor from the dryer and cooker.The press cake, sludge

    and stickwater concentrate is mixed together and is dryed in the

    disc dryer.

5.After drying process, the fish meal have to be cooled to room

   temperature by a cooler.

   Usually the fish meal shall be grindered to fine particles before                packing. After grinding, the fish meal shall be transported by an

   air-cooling screw conveyor before it is packed in a packing tank.

Technical parameters of fish meal processing equipment:

Any questions and inquiry you are warmly welcome :
