Home > Products > 2 layers PCB > Double side FR4 Printed Circuit Board prototype as fast as 24 hours
Double side FR4 Printed Circuit Board prototype as fast as 24 hours
- 1000000 Piece / Pieces per Month
- shekou
- T/T PayPal
- 1 days
You May Like
Product Details
| Brand Name | JHHY | Place of Origin | China | |
| Model Number | FR4-Tg130 | Surface Finishing | HASL lead free | |
| Min. Line Spacing | 0.1mm (4mil) | Min. Line Width | 0.1mm (4mil) | |
| Min. Hole Size | 0.2mm | Board Thickness | 1.6mm（0.062 in) | |
| Copper Thickness | 1OZ (35um) | Base Material | FR4 |
Product Description
Quick Details:
layers | Material | Length | Width | Thickness | Copper Weight | Soler Mask | Silk Screen | Surface Finish | Panelization /Routing |
2 | FR4 | 97mm | 35mm | 1.6mm (0.062 in) | 1OZ (35 um) | Green | White | Immersion Gold | Individual |
Why Chose US:
1. NO MOQ.
2. Cheap and transparent price.
If your PCB meet the specs as below, the price is US$ 5.00 for 10 PCS.
layers | Material | Length | Width | Thickness | Copper Weight | Soler Mask | Silk Screen | Surface Finish | Panelization /Routing |
1/2 | FR4 | ≤100 mm | ≤100 mm | 1.0mm/ | 1OZ (35 um) | Green | White | HASL | Individual |
For bulk order, our prices are as below:
Layers | Qty/sq.m | Thickness/mm | Price | Remark |
1 | 1 | 0.6-1.6 | 52.40 | Engineering Fee: $ 10.00 |
1 | S>10 | 0.6-1.6 | 46.00 | No extra charge |
2 | 1 | 0.6-1.6 | 54.00 | Engineering Fee: $ 10.00 |
2 | 10 | 1.6 | 52.40 | No extra charge |
2 | 20 | 1.6 | 49.20 | No extra charge |
2 | S>50 | 1.6 | 47.60 | No extra charge |
*Prices above are for: HASL, green solermask, white silkscreen, 1OZ copper weight.
*For multiple layers and other specs, please contact sales for detailed quotation.
3. Lead time can be as fast as 12 hours.
4. Able to produce PCB with special request such as: Half-cut/Castellated Holes, Edge Plating, Impedance control, Buried/blind vias, Carbon Mask, Via filled with resin, etc.
5. 100% test.
6. Fee re-produce & delivery if any quality problem.
7. Free re-produce & delivery if package missing.
8. Professional engineer team provide free file modification.
About JHHY
1. Established in 2005.
2. Own 2 factories, the old factory located in Longgang distrcit, Shenzhen City, and the new factory located in Guangming District, Shenzhen City.
3. Over 370 employees in 2018.
4. Able to produce 1-24 layers PCB.
For more information, please visit: www.jhhy-pcb.com
