XH7126 Milling Process Cnc Mill Controller Vmc Machine
- Qingdao or Shanghai
- T/T Credit Card
You May Like
-
XK7124 Vertical Low Cost Hobby Mini Cnc Milling Machine
-
XK7136 Vertical High Precision Hobby Mini Cnc Milling Machine
-
Vmc850 Hot Sale China Factory Price 3 Axis Cnc Vertical Machining Center
-
Xk7124 Cheap 240v 3 Axis Automated Cnc Milling Machine for Sale
-
VMC850 High Precision Vmc Machine Cnc Milling Controller
-
Vmc850 High Speed Fanuc Controller Cnc Milling Machine Automatic Tool Changer(16type)
Product Details
| Brand Name | Luyoung | Place of Origin | Shandong, China | |
| Model Number | XH7126 | After-sales Service Provided | Engineers available to service machinery overseas | |
| Condition | New |
Product Description
XH7126 milling process cnc mill controller vmc machine
Item | XH7126 | ||
Table size (mm) | 800×260 | ||
T-Slot Q-W(mm)–Distance(mm) | 5-16-50 | ||
Max,load (kg) | 150 | ||
Travel of X axis(mm) | 410 | ||
Distance from center of spindle to Column guideway (mm) | 315 | ||
Taper hole of spindle | BT30 | ||
Max speed of spindle (Rpm) | 8000 | ||
Power of main power(kW) | 2.2 | ||
Motor of feeding | X Torque (N.M) | 5 | |
| X Torque(N.M) | 5 | |
| X Torque(N.M) | 6 | |
| Max,dimension of installation | XY Square 110×11diameter φ95 | |
X,Y,Z Rapid feed rate (m/min.) | 10 | ||
fast cutting speed (mm/min) | 1-4000 | ||
Screw parameters(ø mm/screw pitch mm) | XY 20/5 | ||
| Z 25/5 | ||
Width of liner guide rail X/Y/Z(mm) | XY 20 | ||
| Z 25 | ||
| Time of tool changing |
| 8 |
Operation pressure Mpa | 0.6 | ||
Weight kg | 1700 | ||
Dimension | |||
XH7126 milling process cnc mill controller vmc machine is controlled by X, Y and Z coordinates, and the main axis is variable frequency (servo) power drive.XH7126 milling process cnc mill controller vmc machine Can be achieved for a variety of plate, plate and shell, a complex parts, such as CAM, mold clamping, drilling, milling, boring, expansion, hinge, (tapping), and other process, are suitable for many varieties, small batch parts production, complex, high precision parts processing can show its superiority.
1. The base, sliding seat, table, column, main shaft box and other main basic parts adopt high rigid cast iron structure, which guarantees the high rigidity and anti-bending performance of the basic parts;Based on the resin sand molding and aging treatment, the precision stability of the machine tool is ensured for the long-term use of the machine.
2. X, Y and Z go in three directions to the high-precision high-strength ball screw with famous brand, and the feeding speed is high, and the positioning accuracy of the machine tool is high.
3, X, Y and Z guide rail and lead screw are all sealed to ensure the cleaning of the screw and guide rail to ensure the transmission and movement accuracy of the machine tool;
4. The external protection of machine tools is designed in a fully enclosed structure, which is safe and reliable;The semi-protective structure can be used.
5. The operating system of the machine is designed with ergonomic principles and easy to operate;
6. Adopt the advanced centralized lubrication device, and the work is stable and reliable;
7. The XH7126 milling process cnc mill controller vmc machine is equipped with the famous brand CNC system at home and abroad, which can be imported into the famous CNC control system, with complete functions, simple operation, stable precision and reliable.
Taian Lu Young Machinery Co., Ltd is a modern and high- tech company which is a professional manufacturer of CNC LATHE, CNC MILLING, CNC MACHINE CENTER. With 50000sqm workshops and offices, we have more than 20 years experiences in cnc machine research and production.Our products all pass CE Certification,and our factory pass ISO9001Quality Certification.Our machines have been exported more than 40 countries and have been well received by our customers.we welcome all customers and friends come to visitour factory! Regarding the technical force, we have the most professional research and development staff, who can meet all different requirements on.
We have 20 years of accumulated experience in CNC lathe and CNC milling machine,so our products has been exported more than 40 countries. We have professional engineers who are responsible for every product we export. Because of our high degree of professionalism , good quality, factory price and the best service,more and more customers choose us, so our export volume of products increased by 20 percent compared with last year.

The packaging and shipping of XH7126 milling process cnc mill controller vmc machine:
On the mechanical packaging, we use the fumigation-free plywood.Fumigation-free wooden keel support bar is adopted by the export of LVL material, wood is made from multi-layer plywood custom-made, multi-layer plywood and LVL material are after high temperature sterilization and glue them into a wooden . The wooden box itself does not have any log, so it does not need to be fumigated to be exported directly.The goods are well packed in good condition and can prevent the breakage and leakage of the contents during the shipping process.We will adopt Marine transportation to prevent the turbulence and vibration of the transportation process from causing damage to the goods and ensure that the goods are safe and sound when delivered.
1.Company strength.We have 20 years experiences for cnc machine profuction.
2.Friendly price.We supply friendly factory price to help you establish your advantage in your local market
3.Training for free. We can supply training for you in our factory for free.Oversea service also is OK.
4.Relationship.We will establish long-term relationship with our clients.
1.Professional technogoly service team.we have professional technogoly service team , we supply one by one solution design for your request.
2.Training for free and oversea service.we can supply training for your in our factory for free.Oversea service also is OK.
3.7*24 hours online sales.We supply 7*24 hours online sales and after sales service for free.And we welcome customers to visit our workshop and products at any time.
4.Replacement parts for free.We supply replacement parts for free if the machine is proved defective within 12 months.
Our company has exported all kinds of mechanical products to more than 40 countries.We provide suitable products for different countries and provide the best and most thoughtful service for our customers.
We attended a lot of mechanical trade fair, in the fair, we talk about products with customers, and invite customers to visit our production workshop, understanding of mechanical manufacturing process, thus expanding the overseas market. If customers have special product requirements, we can also customize them according to customer needs.
1. What’s the term of payment ?
As usual, Our term of payment is:
30% downpayment by T/T (Telegraphic transfer ) in advance.
70% by T/T before shipment.
Besides, We can also accept term of payment by irrevocable letter of credit at sight. D/P or D/A.
2. What’s the quality warranty ?
We will supply standard parts and accessories with our machines when shipment. Within one year after receiving our machines, In the right operation, If there are any damaged parts or accessories, We will replace them by air-mail or express mail immediately free of charge.
3. What’s the delivery time ?
We will supply goods to you within 1 months after getting your 30% downpayment by T/T according to the different products.
4. What’s the charge of installing and commissioning ?
For some machines, It need our technician to go to your local site and help you install and commission machines. At the same time, Our technician will train your workers. It will take 7-15 days for different machines. The return air-tickets, accommodation, food, salary ( USD60.00/day for every technician ),etc will be born by the end-user.
