Home > Products > CNC milling & machining center > New CNC Vertical Milling Machine VMC Machine Price VMC650
New CNC Vertical Milling Machine VMC Machine Price VMC650
- Qingdao shanghai tianjin lianyungang etc
- T/T Credit Card
You May Like
-
Low Price 3 Axis CNC Milling Machine VMC 850 Vertical Machining Center From China Supplier
-
VMC 5030 Vertical Machining Center or Cnc Milling Machine,cnc Vmc
-
VMC5030 Small Vertical Cnc Milling Machine for Metal
-
VMC3020 3 Axis Mini Small Cnc Milling Machine for Sale
-
Chinese Small High Precision Cnc Cutting Milling Machine VMC3020
-
China Manufacturer Price Cnc Vertical Milling Machine VMC3020
Product Details
| Brand Name | HIENCE | Model Number | VMC650 | |
| Type | Vertical | Certification | ISO9001 CE | |
| After-sales Service Provided | Overseas service center available | Warranty | 1 Year | |
| Weight | 4800kgs | Dimension(L*W*H) | 2650*2150*2550mm | |
| Voltage | 380V | Condition | New |
Product Description
Vertical Machine Center VMC650
| VMC650 |
X travel (mm) | 650 |
Y travel (mm) | 400 |
Z travel (mm) | 450 |
Table size(L×W) (mm) | 760×400 |
Max load (kg) | 400 |
Spindle center to column (mm) | 575 |
Spindle nose to table (mm) | 100~600 |
Linear guideways | Taiwan roller |
Linear guideways width (mm) | 35 |
Ball screw | 4012 |
X,Y,Z cutting speed (mm/min) | 1-6000 |
X,Y,Z fast speed (m/min) | 36/36/32 |
Spindle speed(r/min) | 50~8000 |
Spindle taper | BT40 |
Automatic tool changer(Funnel type) | 16 |
Spindle motor (kw) | 5.5 |
T slot(mm)quantity×width×distance | 5/18/75 |
Accuracy (300mm) | 0.005 |
Repeatability accuracy(300mm) | 0.003 |
Air pressure (Mpa) | 0.6 |
Size (L×W×H)(m) | 2.65*2.15*2.55 |
weight(T) |
Standard accessory | Optional accessory |
Fanuc-0i-mate-MD | Mitsubishi M70/GSK218M |
full enclosure machine guard | Funnel type tool changer |
Arm type ATC | chip cart |
automatic central lubrication system with alarm | 4th axis |
Z axis counter-balance weight | Metrol tool setters |
spindle cooling unit | transformer to suit local power supply |
spindle side air blow | screw type chip conveyor |
machine window with safety glasses | |
rigid tapping | |
auto power off | |
3 colours warning lamp | |
work lamp | |
leveling pads&bolts | |
operation manuals | |
tool holder and pull stud |
