High Precision CNC Vertical Educational Type Milling Machine Center Price VMC300

FOB Price

US$ 16,000 - 18,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HIENCE		Place of Origin	Shandong, China
After-sales Service Provided	Engineers available to service machinery overseas		Condition	New

1 Security locks, lubricating system,

Cooling tank and dust pans, operation indicator light (red, yellow, green), working lamp, air gun, toolbox, a set of instructions.

SIEMENS system

ITEMS	Specifications
Table size (mm)	450×160mm
T type groove (Number-width(mm)	3-12
Max. Drilling diameter(mm)	13
Maximum milling diameter(mm)	13
The fastest tool change time	4s
Travel of X axis (mm)	300
Travel of Y axis (mm)	175
Travel of Z axis (mm)	270
The spindle end to the work surface(mm)	320
From working table to the ground height (mm)	780
Highest speed of spindle(Rpm)	100-24000
Power (kW)	1.5
Rapid feed speed of X/Y/Z axis (mm/min)	10000
Fast cutting speed of X/Y/Z axis(mm/min)	1-4000
repeated positioning accuracy (mm)	0.02
Weight(kg)	450
Dimension(mm)	1360× 990 ×1800 mm
Voltage	AC220V/50Hz

100% Response Rate

100% Response Rate

100% Response Rate

Packing & Delivery

Packaging
Packaging Details	The normal package is wooden box(Size: LWH). the wooden box will be fumigated.
