China Hot Sale 8 Inch to 20 Inch Hydraulic Cutter Suction Dredger

FOB Price

US$ 1,200,000 - 1,500,000 / Unit

1 Unit(Min. Order)

Port QINGDAO or TIANJIN port
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Sinoking	Place of Origin	Shandong, China
Model Number	SJ-CSD	Type	Cutter Suction Dredger
Certification	ISO9001:2008	After-sales Service Provided	Overseas service center available
Warranty	12 Months	Weight	260T
Dimension(LWH)	428.52.1m	Power Type	Diesel
Condition	New	Draught	120 cm
Dredging Depth	16 m

Product Description

Our advantage

WHY CHOOSE US?

1-Established in 2002,14 years cutter suction dredger manufacture experience
2-Processing capacity from 500 m3 to 5000 m3 per hour
3- Individual-customized design according to your require
4- Field survey by the engineers
5- Engineers available for overseas installation and training.
6- High efficiency with less money
7- Long life, durable cutter suction dredger.
8- Worldwide shipping by our own forwarder.

WHY CHOOSE OUR CUTTER SUCTION DREDGER?

1-Full hydraulic system and advanced PLC control system
2-High efficiency and minimum fuel consumption and operational costs
3-Spare parts available and best after-sales service is provided
4-12 months warranty for the main parts
5-Easy assembly & disassembly
6-One person can operate

Product details

The parameter of 8 inch to 20 inch cutter suction dredger
Model of cutter suction dredger	SJ-CSD500	SJ-CSD450	SJ-CSD350	SJ-CSD300	SJ-CSD250	SJ-CSD200
Total Length* Width* Height	458.62.2m	4282m	357.52.0m	356.01.8m	285.61.8m	225.21.8m
The main pontoon size	203.82.2m	203.32m	193.31.8m	192.61.8m	122.41.8m	102.21.8m
The max dredging depth	16m	16m	13m	12m	12m	9m
Working capacity	5000m3/h	3500m3/h	3000m3/h	2000m3/h	1200m3/h	900m3/h
Discharge distance	1500m	1500m	1500m	1000m	1000m	500m
Pump manufacturer	Shijiazhuang pump	Shijiazhuang pump	Shijiazhuang pump	Shijiazhuang pump	Shijiazhang pump	Shijiazhang pump
Pump model	Wn500	20/18"	16/14"	14/12"	12/10"	10/8"
Pump shaft power(driven by gearbox)	1200kw	1090kw	700kw	400kw	282kw	210kw
Main engine manufacturer	Cummins	Cummins	Cummins/ Weichai	Cummins/ Weichai	Cummins/ Weichai	Cummins/ Weichai
Diesel engine power	1641kw	1350kw	895kw	746kw	426kw	336kw
Rotation speed	1800rpm	1200rpm	1800rpm	1800rpm	1800rpm	1800rpm
Cutter shaft power	260kw	170kw	150kw	120kw	90kw	60kw
Cutter diameter	2000mm	1800mm	1600mm	1500mm	1300mm	1100mm
Cutter rotation speed	30rpm	30rpm	30rpm	30rpm	30rpm	30rpm
Ladder winch	1 set	1 set	1 set	1 set	1 set	1 set
Swing winch	2 set	2 set	2 set	2 set	2 set	2 set
Spud length	23m	20m	19m	16m	16m	13m
Spud diameter	677mm	550mm	510mm	450mm	377mm	377mm
Spud tickness	30mm	20mm	20mm	20mm	16mm	16mm
Spud quantity	2 pcs	2 pcs	2 pcs	2 pcs	2 pcs	2 pcs
