10ton Crane Truck, Truck Crane for Sale, Crane for Truck
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Brand Name | MAP | Place of Origin | Shandong, China | |
| Model Number | MAP10T | Certification | ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | 1 year after arrived at destination port | |
| Application | Construction | Condition | New | |
| Max. Lifting Load | 10000KG | Span | 2250~5110mm | |
| Rated Lifting Moment | 240KN.M | Rated Loading Capacity | 10T | |
| Max. Lifting Height | 26.5M |
Product Description
10ton crane truck, truck crane for sale, crane for truck
Product Description
The truck crane is a good product of Weifang MAP POWER.It's a small crane,widely used in small construction works and have a good expression to the cuntomers.
The specification of truck crane MAP10T
| The specification of truck crane MAP10T | |
| Total mass kg | 9640+500 |
| Overall dimension mm | 8950*2360*3040 |
| Rated elevating capacity kg | 10000 |
| Rated Lifting torque kn*m | 240 |
| Max. Lifting Height m | 26.5 |
| Main hook single load kg | 1500 |
| Main hook single elevating speed m/min | 50 |
| Auxiliary hook single load kg | 500 |
| Auxiliary hook single elevating speed m/min | 100 |
| Engine model | YANGCHAI 4102(YZ4DA7-30) |
| Derailleur model | LG5-38 With high and low speed auxiliary box |
| Tires | 8.25-16 with spare tires |
| Braking form | Break air brake |
| Steering form | Hydraulic power steering |
| Crane jib structure | Category five hexagon box-type, hydro cylinder telescopic boom |
| Main Lifting Mechanism | Category two planet wheel with a brake inside |
| Auxiliary Lifting Mechanism | Category one gear brake motor |
| Swing Bearing | GB Φ1000 Tooth, material 50Mn intermediate frequency |
| Vertical hydraulicleg | Double-acting engineering oil cylinder |
| Horizontal hydraulicleg | Double-acting engineering oil cylinder |
| Platform | Anti-skidding and big |
| Protective Screening | Two-way |
| Night light | 3 lamps control |
| Dynamic Motor | GB 11KW-4 pole |
| Crane Cab | Tailor-made |
| The central axially symmetrical | Four oil ways |
| Crane Start | Tailor-made |
| Throttle | Hydraulic |
| Warning Horn | Mono snail |
| Pressure gage and switch | Shockproof component |
| Power Takeoff | Driving indoor operation zip type |
| Hydraulic Oil Tank | Turntable rearmounted, counter weight combined type, special four-layer filters |
| Load displayer/ Lift height limiting stopper | Optional |
