Glass Mosaic Cutting Machine
- Shanghai Ningbo Qingdao
- T/T Credit Card
You May Like
Product Details
| Brand Name | JINGLING | Place of Origin | Anhui, China | |
| Model Number | JQZ-700 | Certification | CE | |
| Machine Type | Glass Cutting Machine |
Product Description
JQZ-700 Mosaic Glass Cutting Machine
Characteristic
High efficiency cut with multiple cutters
Cutting box can be increased
Self-lubricating cutter holders
Easy-replaced cutter wheel
High density table panel
Mechanical parts
Name | Brand |
Table surface panel | High-density waterproof panel, roughness≤±0.20mm/m (Imported material) |
Technical parameter:
Model | Max. glass size | Thickness | Dimensions (L*W*H) | Min. size | Weight |
JQZ-600 | 550*550mm | 0.7~15mm | 1280*1260*1040mm | 15*15mm | 300kg |
JQZ-700 | 680*580mm | 0.7~15mm | 1400*1300*1040mm | 15*15mm | 350kg |
JQZ-800 | 700*650mm | 0.7~15mm | 1400*1510*1140mm | 15*15mm | 550kg |
JQZ-1510 | 1400*900mm | 2~15mm | 2150*1710*1140mm | 15*15mm | 650kg |
JQZ-1612 | 1500*1100mm | 2~15mm | 2248*1910*1140mm | 15*15mm | 850kg |
JQZ-1613 | 1500*1200mm | 2~15mm | 2248*2010*1140mm | 15*15mm | 850kg |
JQZ-16135 | 1500*1250mm | 2~15mm | 2248*2060*1140mm | 15*15mm | 850kg |
JQZ-2116 | 2000*1500mm | 2~15mm | 2748*2310*1140mm | 15*15mm | 1500kg |
JQZ-2317 | 2200*1600mm | 2~15mm | 2948*2410*1140mm | 15*15mm | 1550kg |
JQZ-23175 | 2200*1650mm | 2~15mm | 2948*2460*1140mm | 15*15mm | 1550kg |
JQZ-23185 | 2200*1750mm | 2~15mm | 2948*2560*1140mm | 15*15mm | 1550kg |
JQZ-2320 | 2200*1900mm | 2~15mm | 2948*2720*1140mm | 15*15mm | 1580kg |
JQZ-2620 | 2500*1900mm | 2~15mm | 3248*2720*1140mm | 15*15mm | 1600kg |
JQZ-2621 | 2500*2000mm | 2~15mm | 3440*2870*1140mm | 15*15mm | 1600kg |
JQZ-3026 | 2900*2500mm | 2~15mm | 3844*3385*1140mm | 15*15mm | 1800kg |
JQZ-3526 | 3400*2500mm | 2~15mm | 4344*3385*1140mm | 15*15mm | 2000kg |
JQZ-3725 | 3660*2440mm | 2~15mm | 4544*3285*1140mm | 15*15mm | 2000kg |
JQZ-4026 | 3900*2500mm | 2~15mm | 4980*3385*1140mm | 15*15mm | 2200kg |
