DN Series Pneumatic-AC Spot & Projection Welding Machine
- Huangpu Port, Guangzhou
- T/T Cash
- 20 days
You May Like
Product Details
| Brand Name | DUROWELDER | Place of Origin | China | |
| Model Number | DN | Certification | CCC | |
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | one year | |
| Weight | 110KG | Voltage | 380V | |
| Usage | welding | Condition | New | |
| Power(W) | 100KVA | Dimensions | 900CM*500CM*150CM | |
| Rated Duty Cycle | 50% | Rated Capacity | 100KVA | |
| Max. Welding Thickness | 3MM+3MM |
Product Description
DN Series Pneumatic-AC Spot & Projection Welding Machine
l Manufactured in accordance with international ISO Standard.
l European CE Certified
l European Type Microprocessor Welding Control has transparent safety cover to protect a keypad and has a lock to allow only authorized personnel to access the program.
l Welding Control maintains main parameters such as welding current; weld time, off time, etc. with digital accuracy.
l Any of 23 weld schedules can be easily selected for execution.
l Rigid Frame of the Machine allows the use as Projection or Spot welder.
l Improved water-cooling system guarantees flawless performance in heavy-duty applications.
l Machine is painted with Lead-Free paint.
l All materials used in design are environmentally friendly.
| Rated | Rated | Rated | Max. | Rated | Arm | Maximum | Electorode | Cooling | Weight | Electrode size | ||
| Electrode |
|
| ||||||||||
KVA | V | Hz | A | % | mm | N | mm | L/min | Kg | (mm) | (mm) | (mm) | |
DN-25 | 25 | 380 | 50/60 | 17500 | 50 | 380 | 2500 | 60 | 6 | 300 | 16 | 20 | 45*200 |
DN-35 | 35 | 380 | 50/60 | 18500 | 50 | 380 | 4000 | 60 | 6 | 380 | 16 | 25 | 50*200 |
DN-50 | 50 | 380 | 50/60 | 20000 | 50 | 380 | 6280 | 60 | 6 | 430 | 16 | 25 | 50*200 |
DN-75 | 75 | 380 | 50/60 | 25000 | 50 | 380 | 6280 | 60 | 8 | 500 | 16 | 25 | 60*200 |
DN-100 | 100 | 380 | 50/60 | 30500 | 50 | 380 | 6280 | 60 | 8 | 600 | 16 | 25 | 60*200 |
DN-150 | 150 | 380 | 50/60 | 38500 | 50 | 380 | 6280 | 60 | 12 | 750 | 20 | 30 | 80*250 |
DN-200 | 200 | 380 | 50/60 | 43000 | 50 | 380 | 6280 | 60 | 12 | 800 | 20 | 30 | 80*250 |
