5V1A single USB port power charger for mobile phone with CE certificate for EU standard

FOB Price

USD $1.1 - $1.8 / Piece

500 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Product Description

5V 1A CE FCC GS certified US standard AC/DC adapter

Input & Output	Voltage/Frequency Range	100~240VAC 50/60Hz
	Input Current	≤0.3A
	Rated Output	5W(Max)
	Line/Load Regulation	±2% / ±5%>
	Ripple&Noise(Max)	≤>200mV
Reliability	Withtand Voltage	I/P-O/P:3KVAC,60s, 5mA>
	Leakage Current	0.25mA / 240VAC>
	Isolation Resistance	I/P-O/P:100M Ohms / 500VDC / 25 / 70% RH>
	MTBF	30000hrs full load,based on MIL-HDBK-217F(25℃>) (>30000hrs , MIL-HDBK-217F(25℃>)
	Temperature Rise	80~100% load, 4hours
Protection	Over Load	>105% rated output power
	Over Current	110%-150% rated output current
	Short Circuit	Recover automatically after fault condition is removed
Safety	Safety Standard	UL60950-1, CSA22.2,IEC/EN60950 IEC/EN60065>
	EMI	Compliance to FCC part15 class B, EN55022, EN61204-3 class B>
	EMS Immunity	Compliance to EN61000-4-2,3,4,5,6,8,11, ENV50204>
	Harmonic Current	Compliance to EN61000-3-2,3>
EnViroment Protection &Efficiency	RoHS	Compliance to CPSIA(H.R.4040
	No Load power consumption
	Efficiency	IV or V>
Package	Dimensions	93×47×54mm (LWH)
Package	Packing	PE bag or white box>
Environment	Working Temp	0 ~ +50 (℃>)>
	Working Humidity	20% ~ 90% RH non-condensing>
	Storage Temp	-20~85(℃>),10 ~ 95% RH
