Servo Motor | ABB | 3HNP03386-1

Contact: Sandy Lin

Email:unity@mvme.cn

Skype:onlywnn_1

Telegram:+8618020776786

Mobile(Whatsapp): (+86)-18020776786

QQ :2851195456

Packing & Delivery

• 100% full New! - Original Factory Seal !

• Warranty: 12 months!

• Package: Original packing with cartons.

• Delivery time: Shipped in 3 days after payment

Best Quality Assurance:

• We only provide the original new items, 100% make sure the best quality!

• 2.1 year warranty GUARANTEE OF QUALITY (After Our Delivery Date).

Servo Motor | ABB | 3HNP03386-1

Servo Motor | ABB | 3HNP03386-1

Servo Motor | ABB | 3HNP03386-1

In most cases, the ambient temperature for the operator panel is significantly higher

than the device cabinet’s ambient temperature.

If the cabinet is tall and there are a number of heat-generating devices, the

temperature at the top of the cabinet will be considerably higher than the theoretical

temperature increase that would be expected. All electronics are sensitive to heat.

The lifespan of an electrolytic capacitor is cut in half with an 8-10 °C increase in

temperature. A 15-20 °C temperature increase results in a quarter of the lifespan etc.

Rittal has a good program for estimating the anticipated average temperature in the

cabinet as well as a large program for controlling the temperature in the device

cabinet.

An enamel-coated steel cabinet has a radiant heat value of 5.5 W/m2 and °C.

Installing a fan inside the cabinet will even out the temperature, while moving air

provides considerably better cooling than still air. A suitable fan is a 120 x 120 mm

axial fan, available in 24 V DC, 115 and 230 V AC.

Install the fan so that it sits in the cooler area and will blow cold air against the

operator panel. If the fan is mounted at the top and sucks air upwards, the fan’s

ambient temperature will be higher = shorter lifespan.

A good fan with a ball-bearing mounting has an expected lifespan of at least 40,000

hours (not a guaranteed lifespan) at 40 °C. This corresponds to at least 4 years of

continuous use. If a thermostat is installed, the fan only needs to come on when

needed.

Large graphic terminals draw only one fifth of the current when the background

lighting is off. The loss effect drops from e.g. 25 W to only 5 W.

The operator panel’s loss effect = supply voltage x current. Virtually no power goes

to external users and no loss effects due to inputs.
