Product Description

Huawei ATN 910 AND1EF8T - 8 Channels Fast Ethernet Electric Interface Board

Indicator

The following indicators are present on the front panel of the AND1EF8T:

STAT indicator, red, green, or orange, which indicates the working status

LINK indicator, green, which indicates the connection status of the port

ACT indicator, yellow, which indicates the data transceiving status of the port

Functions and features of the AND1EF8T

Function and Feature	Description
Basic function	Provides eight FE electrical interfaces.
	Supports the hot swappable function.
	Detects the temperature and voltage of the board.
Interface function	Supports signals at 10 Mbit/s and 100 Mbit/s.
	Supports inloops and outloops.
	Supports Layer 2 and Layer 3 working modes.
Clock	Supports physical-layer clock synchronization (synchronous Ethernet).
Clock	Supports IEEE 1588v2 and IEEE 1588 ACR.
