Copper Coating Machine ,arc Spraying Machine SX600
- Guangzhou
- T/T
- 3 days
You May Like
-
Rough Surface Treatment Machine ,surface Roughing Machine,surface Treatment Machine
-
Metal Surface Rougher Treatment Machine
-
Red Copper Coating Machine ,arc Spray Machine SX600
-
Ni-Cr Chrome Carbide HVOF Coating Machine
-
Yellow Copper Coating Machine , Arc Spray Machine SX600
-
HVOF Coating Machine for Repairing Papermaking Machine Parts
Product Details
| Brand Name | sanxin | Place of Origin | China | |
| Model Number | 10 | After-sales Service Provided | Engineers available to service machinery overseas | |
| Condition | New |
Product Description
Are you looking for the copper coating machine ? Do you have difficulties in dealing with the broken copper workpieces ? Maybe our arc spraying machine SX600 can help you .
our factory is committed to spraying technology research for more than 30 years ,we have dozens of spraying equipment ,such as thermal spraying equipment,arc spraying equipment ,plasma spraying equipment ,and so on
SX-600 is one kind of arc spraying equipment,it is used for spraying zinc,aluminum,copper,molybdnum,titanium,stainless steel,high carbon steel,nickel chromium alloy,wear-resistant alloy,Babbitt alloy material,etc.
(1) principle of copper coating machine SX600
This high velocity arc spraying (high velocity arc spraying) is a technology which uses arc to melt metal,the arc is formed by combustion in two continuous feeding metal wire,then the melting metal is atomized by high speed airflow.Through the laval nozzle,the atomizing metal particles are accelerated to make them to exceed supersonic to spray to the workpieces to form a coating
(2)component of copper coating machine SX600
It is a new technology based on the normal arc spraying ,which is composed of a special power supply, an arc spray gun, a push type arc spraying device, and a wire feeder.
arc spray machine arc spray gun

(3) parameter of copper coating machine
Arc spray gun parameters:
Model | Arc spray gun |
Operation mode | Handed or fixed |
Input voltage | ≤24V(DC) |
Applied wire diameter | Φ1.2 Φ1.6 Φ2.0 Φ3.0 mm |
Air pressure | >0.5Mpa |
Air consuming | >1.85m3/min |
Wire feeding gravitation | >8kg |
Feeding velocity regulating grade | Stepless speed regulating |
Weight | 2.65kg |
Metal wire parameters:
Spray material | Wire diameter | Working current | No-load volt | Air hat diameter | Maximum spray efficiency |
Zinc wire | 1.2-3.0 | 80-210 | 18-30 | 6-8 | 30 |
Al wire | 1.2-3.0 | 120-240 | 25-38 | 6-8 | 9.5 |
Steel wire | 2.0 | 150-200 | 35-40 | 7-8 | 6 |
High carbon steel wire | 2.0 | 150-220 | 10-44 | 8 | 5.5 |
Stainless steel wire | 2.0 | 150-220 | 10-44 | 8 | 5.5 |
Zn-Al, Pb-Sn alloy wire | 1.2-2.0 | 80-110 | 18-28 | 7 |
(4)advantage of copper coating machine
1) Stable and convenient
This equipment is improved in the operation program by integrated circuit to prevent from machine damage by misoperation of workers, so as to protect the safety of operators and the equipment.
2) High adhesive force of coating(70Mpa)
Compared with 30-40Mpa of common arc’s coating,the adhesive force of coating can reach 70Mpa.
3) Workpiece won’t be deformed and its structure won’t be changed.(<100℃)
Generally the rised temperature of workpiece won't exceed 100 ℃ when spraying, so the workpiece won't be deformed. And the spraying heat won't take effect directly on the surface so it doesn’t change the structure of workpiece.
4) High efficiency and wide application
The equipment has high spray efficient and high power; It's suitable for on-site construction, and can use all kinds of metal and metal ceramic materials(solid and without core), such as alloy wires, Mo, Al, Zn, red copper, copper alloy, Babbitt etc. It is widely applied in spraying anti-wearing and anti-rust coatings for boiler’s four kinds of tubes, coal pulverizing system (fan impeller and scroll casing), roller, dryer, axis, mould,all kinds of workpieces and so on.
5)Spray gun for long distance(30-meter-long-cable)
The spray gun can be equipped with 30-meter-long cable, air tube and 8-core control cable, so it can spray at remote places about 30 meters from the equipment.
6)Unnecessary to change the wearing parts frequently
We have patent conductive nozzle which is anti-wearing and greatly enlarges use time of wearing parts. This helps to reduce the spraying cost and improve working’s efficiency and coating’s quality.
7)Convenient maintainance and repair
We take maintainance and repair work into our consideration during designing the equipment and spray gun which make it convenient to maintain and repair.
(5)our products and customers :
our products are taken strict quality control ,Our customers are from a lot of countries in the world, we have established long term cooperation with them,some photos for reference :
(6)our service:
we can offer you the user manual to help you start the machine ,also,our technologist can go abroad to instruct you , also, we can send you live video by wechat ,in fact ,most of our foreigner customers do it by our manual and video ,
If you are interested in ,please contact me ,I will offer you more details accordingly ,thanks
