Computer Control Electromechanical Universal Testing machine with Protective Cover

30kN/50kN/100kN Electromechanical Universal Testing Machine with Protective Cover

1 Important function

1) test research for tension, compression, flexure, torsion, shearing test with metal, nonmetal and composite material under room temperature.

2) thin panel, board, belt, foil, flat material, wire, bar, sectional bar, pipe, sheet, square, round, rectangle, and ring shaped, cast iron, alloy of cast iron,  part of tube, proportional sample(proximate coefficient k=11.3 or 5.65), non-proportional sample, sample for longitudinal split of whole thick, sample for horizontal split of whole thick, cross section of rectangular sample, cross section of round sample.

3) test for property with thin metal, wire, fine wire, fiber, elastomer, foam.

4) test for property with textile, food, medicine, cosmetic, rubber, plastic, film, biological material.

5) test for tensile, peeling, welding strength with components.

6) test for peeling, bending, fastener property with printed circuit board.

7)  tensile test with wooden product, paper production, film.

2 Standard

1) ASTM E8 / E8M - 16a Standard Test Methods for Tension Testing of Metallic Materials

2) BS EN ISO 6892-1: Metallic materials. Tensile testing. Method of test at room temperature

3) ASTM E9 - 09 Standard Test Methods of Compression Testing of Metallic Materials at Room Temperature

4) ASTM D695 - 15 Standard Test Method for Compressive Properties of Rigid Plastics

5) ASTM D4018 - 17 Standard Test Methods for Properties of Continuous Filament Carbon and Graphite Fiber Tows

6) ISO 7438: Metallic materials-Bend test

3 Important Specification

1) Load capacity: 30kN/50kN/100kN

2) Accuracy: ±0.5

3) Force range: 0.4%--100%FS

4) Load accuracy of indicated load:±0.5%

5)  Resolution of load: 1/±300000F.S with no change

6) Deformation range: 0.2%--100%FS

7) Deformation accuracy of indicated deformation: ±0.5%

8) Deformation resolution:1/±300000

9) Accuracy of indicated displacement: ±0.5%

10) Resolution of displacement: 0.015μm

11) Range of load-speed: 0.005 -- 5%FS/S

12) Accuracy of load-speed: ±1%

13) Range of strain speed: 0.02 -- 5%FS/S

14) Accuracy of strain speed: speed ＜0.05%FS, between ±2%

                                                speed ≥ 0.05%FS, between ±0.5%

15) Range of speed of crosshead: 0.001 -- 600mm/min

16) Accuracy of speed of crosshead: speed ＜0.01mm/min, between ±1.0%

                                                           speed ≥ 0.01mm/min, between ± 0.2%

17) Range of constant force, strain and displacement: 0.5% -- 100%FS

18) Precision of constant force, strain and displacement:

      set value ＜10%FS, between ±1%

      set value ≥10%FS, between ±0.1%

19) Range of large deformation: 10 -- 1200mm

20) Stroke of crosshead: 1200mm

21) Test span: 510mm

22) Clamping mode: hydraulic

23) Size: 1050*560*2350mm

24) Power: 2000w

25) Voltage: 380±10%, 50Hz

26) Weight: 900kg.
