Purple Energy Release Fiber Optic Cable Coast Guard

Features:

1, optical fiber composite cable, the outer eng_protection for the foam
Polyurethane eng_protective cover, the inner layer of the additional addition of linear tensile material,

2, the number of optical cable core: 2 RV1.5 (0.19 shares) soft cable (diameter 2.65MM)
+2 core single-mode armored fiber (OD 3MM)

3, tensile capacity: ≥ 300kg-500KG.

Description:
1 inner sheath for selection TPE PU foam
2 Outer eng_protective cover Material: PU
3 inner layer of wire filled with tensile material
4 Outer diameter: ≦ 13mm ± 0.2mm
5 Watereng_proof: 500 meters water without water
6 Cable specific gravity: ≦ 1.0 Specific gravity of water
7 Antiseptic: Alkali resistance> PH9, acid resistance <ph6
8, the warranty period: one year
9, tensile strength: ≥ 500kg
10, anti-bending: bending radius can be less than 6 times the outer diameter of the cable, can guarantee repeated delivery 1000 times.
11, cable withstand voltage: 450 / 750V

Parameters:
1, technical specifications: GB / T3956
2, material standards: GB / T3953
3, cable core number: 2 RV1.5 (0.19 shares) soft cable (diameter 2.65MM)
+1 single 2-core single-mode armored fiber (OD 3.3MM)
4, fiber standard: G.657A2 / G652.D
5, fiber attenuation requirements:

Fiber attenuation	1310nm	≤0.35dB/km
	1550nm	≤0.21dB/km Contact Us Shanghai DingBai Wire & Cable Co., Ltd Contact nameChen Chat Now Phone86-18019118063 *Email Please enter Your valid email address. *To Chen *Message Your inquiry content must be between 20 to 5000 characters.   Please enter a correct verification code. Send Now Product Categories ROV Cable ROV Umbilical Cable ROV Tether Cable Marine Electrical Cable PUR Cable Polyurethane Cable High Flexible Cable Towline Cable Flat Electrical Cable Drum Reeling Cable Oil Resistant Cable Fiber Optic Cable Geophysical Cable Low Temperature Cable More New Products Electrical Connection Copper Wire Fiber Optic Cable Energy Release Pur High Temperature Resistance Ship Fiber Optic Cable Water Resistance Geophysical Cable 200v 300v / 500v Pu Good Toughness Pvc Coal Geophysical Cable Pvc Coal High Temperature Resistance Geophysical Cable Brown Armoured Logging Geophysical Cable Oil Resistance Good Toughness -45 ℃ -120 ℃ Gray Geophysical Cable Pur Anti-ultraviolet 200v 300v / 500v Geophysical Cable Hydropower Geophysical Cable Cold Resistance Black Construction Copper Wire Wear Resistance Geophysical Cable Anti-ultraviolet Black Armoured Logging Geophysical Cable Waterproof Survey Cable Pink Geophysical Cable Long Life Geophysical Cable Underground Pu Survey Cable Purple Geophysical Cable Anti-jamming Black Geophysical Cable Aging Resistance Underground Anti-jamming -45 ℃ -120 ℃ Tpe Geophysical Cable Weather Resistance Pu Underground Geophysical Cable Water Resistance Electrical Equipment Low Temperature Cable Blue Polyurethane 300/500 V Oil Resistance Low Temperature Cable Metallurgy Low Temperature Cable Yellow Climate Resistance Anti-uv Ports Multi-core Low Temperature Cable Wear Resistance -60 ℃ ~ +100 ℃ Low Temperature Cable Gray Double Insulted Low Temperature Resistance Low Temperature Cable Copper Wire Water Resistance Multi-core Oil Low Temperature Cable Popular Searches spare parts power cable Speaker Cable electric cable phone accessories mobile phone Flexible Pcb mobile phone parts cell phone parts charging port cellphone replacement charger connector mobile repairment sim card reader Welding Cable Electrical Power Cable Connector Terminal Rf Coaxial Connector Crimp Connector Spiral Cable mobile phone flex flex pcb fpcb Electrical Wire Cable Recommended Products New Energy UL2263 Electronic Wire 18AWG Power Battery Flex Cable For iPhone 11-14 Pro Max Application and use environment of liquid-cooled charging cables Application equipment of non-shielded high-voltage wires for new energy vehicles Professional cable manufacturers provide EVRP-125 95 square cable equipment application OMG' manufacturer electric vehicle AC cable obtains dual certification of CQC and DEKRA Electronic Industrial Control Electrical Machine Air Automatic Computer Crimp Cable Assembly Manufacturer 8 Fuel Injector Connector Wiring Plugs Clips EV6 EV14 Pigtail Cut & Splice Tractor Wiring Harness Connectors Customize machine Wire Harness Automotive Wiring Harness Assembly tractor cable assembly OEM ODM RoHS Compliant Custom Machine Wiring Harness Assembly ?Single System Simplified Wire Harness Cable Assembly for Agricultural Machine EVs-EVRP-125 95 square cable - efficient power transmission solution More Find Similar Products By Category Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable Product Tags: optical to composite cable | 2 core electrical wire | electrical flex cable Shanghai DingBai Wire & Cable Co., Ltd Main products ROV Cable ROV Umbilical Cable ROV Tether Cable Marine Electrical Cable PUR Cable Polyurethane Cable Quick link Home Product Categories Company Profile Blog Quality Control Contact Us Sitemap Contact Us Telephone86-18019118063 Mobile18019118063 Chat Now Contact Now Latest Product | Product Update | Latest Company | B2B Articles Copyright ? GoldSupplier.com. All Rights Reserved Sourcing Request *Your EmailPlease Enter your Email Address *ContentPlease enter the content for your inquiry. We will find the most reliable suppliers for you according to your description. Send Now Shanghai DingBai Wire & Cable Co., Ltd AIBot OnlineThis conversation is AI-generated. Contact manufacturer before transaction to confirm info. Chen Welcome to my shop, I'm glad to serve you. Please feel free to send me any questions you may have. * * Please enter a correct verification code. Send Your message has exceeded the limit. Contact supplier for lowest price Customized Request Request Sample Request Free Catalogs Your message has exceeded the limit. Purchase Quantity *Sourcing Details Inquiry About Purple Energy Release Fiber Optic Cable Coast Guard Your inquiry content must be between 10 to 5000 characters. *Email Please enter Your valid email address. Mobile *Verification Code Please enter a correct verification code. Send Send Successfully ! We will contact you as soon as possible！ Continue View
