Double AK4399 With software control decoding module

The product of all parts are original authentic, chastity, pure quality;

The use of high-quality original parts, that is not only guarantee the safety quality , long service life, more important is the powerful guarantee to make the actual performance can meet the design target. The pursuit of first-class quality is our consistent aim.

l  Adopted original AK4399 (2pcs) + WM8805 + NE5534

l  The main circuit of the electrolytic capacitor signal uses the PHILPS famous brand, main filter capacitor using NOVER AUDIO special electrolytic capacitor capacity of 2×4700UF, Coupling capacitance by the top German imports of Weimar capacitor 1UF, adopts the full wave bridge rectifier circuit, ensure the supporting power.

l   The selection of Resistance is five metal resistance, the main circuit adopts the metal film resistor which accuracy is ± 1%, guarantee the signal-to-noise ratio of the product.

l  PCB adopts 1.6mm thickness double-sided board, 2 oz copper thickness, spray tin full process, ensure the current well done through the performance. first-class PCB quality.

l  AK4399 is the high-end decoding chip of AKM, support for 32BIT 192K

l  USB optional

l  Coaxial input and will support to 192KHZ, fiber-optical input will support to 96KHZ

l  Directly display (display input sampling frequency analysis and sampling rate), intuitive and convenient

l  With key switch

The parameters of power supply:

1 two group AC 9V (10W or above per group)

2.1 groups of AC double 12V and double 15V (15W or above)

The above power should be connected at the same time

Board size: 185*133MM

CPU size: 102*38MM

If found that the screen characters too dark, then turn left of the trimming Potentiometer;  if found word shadow, then turn left of the trimming potentiometer.
