FANN Resistivity Meter Model 88C 207960

FANN Resistivity Meter Model 88C  207960

Fann Instrument Company specializes in the design and manufacture of instrumentation for measuring the physical and chemical properties of various fluid properties and especially the measurement of flow and viscosity. Their product line is the most comprehensive offering of instruments and accessories, test kits, and portable laboratories for testing; drilling fluids, completion fluids, fracturing fluids, oil-field cements, and industrial slurries. Fann Instrument Company also provides reagents, supplies, and replacement parts.

Resistivity Meter Model 88C

Manufacturer: Fann Instrument Company

Family Part #: FANN TSI-207960

Used to measure the resistivity of fluids, slurries or semi-solids. These resistivity instruments feature solid-state electronics, and are designed to meet the needs of field and laboratory personnel for resistivity measurement according to API Recommended Practice 13B-1. Conductivity of the medium being measured is obtained by taking the reciprocal of the resistivity measurement. The Model 88C Resistivity Meter is suitable for filtrates, muds, filter cakes or slurries and provides a direct digital readout of resistivity in three ranges: 2, 20 and 200 ohm-meters/meters2.

A built-in temperature probe provides direct measurement of the sample temperature in the transparent cell. The instrument features high accuracy and has a built-in test circuits to check calibration. It is packaged in a lightweight high-density polypropylene case and is suitable for onsite testing. Optional Battery Eliminators are available for use with the Model 88C.

Resistivity Meter Model 88C

These resistivity instruments feature solid state electronics, and are designed to meet the needs of field and laboratory personnel for resistivity measurement according to API Recommended Practice 13B-1. Conductivity of the medium being measured is obtained by taking the reciprocal of the resistivity measurement.

The Model 88C Resistivity Meter is suitable for filtrates, muds, filter cakes or slurries and provides a direct digital readout of resistivity in three ranges: 2, 20 and 200 ohm-meters/meters2.

Resistivity Meter Model 88C

A built-in temperature probe provides direct measurement of the sample temperature in the transparent cell. The instrument features high accuracy and has a built-in Test circuit to check calibration. It is packaged in a lightweight high-density polypropylene case and is suitable for onsite testing. Optional Battery Eliminators are available for use with the Model 88C.

Ordering Information

Part No. Description

207960 Model 88C Resistivity Meter

Specifications

Dimensions 2.8 X 5.1 X 8.3 inches (71 X 130 X 210 mm)

Weight 4 lbs (1.8 kg)

Power Supply Batteries, 4 – 9 volt, alkaline

Range 0.005 – 199 ohm-meters
