Dry powder mortar mixing tank

The dry powder mortar mixing tank can effectively replace the manual field mixing machine, save 4-6 people, and the production efficiency is greatly improved, producing 1 cubic wet mortar on average every 40 seconds. After calculation, using the dry mortar mixing tank can improve the use rate of 8 – 12 percentage points and with cement save about 8% of cement and lime, sand, fly ash and other waste; improve the utilization rate of 2 to 3 percentage points; 1.21% contribution rate and energy saving rate of GDP million, more than 2000 tons of fly ash to reduce, eliminate the construction of ash 20%; reduce carbon dioxide emissions 13 .5 thousand tons.

Dry mortar transport to the site by mortar bulk transport vehicle, will be transported to the dry mortar mixing mortar tank by the vehicle pneumatic conveying system, , and then use the dedusting equipment at the outlet of dust (dust bag). The dry powder mortar in the tank can make the dry mortar fall evenly by its own gravity and the vibration of the vibration motor of the tank body, and flow control is carried out through the butterfly valve connected with the lower end of the tank body, and is opened at the maximum position when normally used. When the dry mortar is put into the mixer, stir in the end promote pre mixer, and then through the spiral propulsion shaft forced type quantitative output, when entering the mixing end, provide a constant amount of water by the water pump, mortar and water after mixing for wet mortar, and through the outlet of constant speed falling, and avoids dust emissions fly ash, carbon dioxide is also greatly reduced.

The storage tank as a carrier of dry mortar stored in the construction site, the bulk of dry mortar mortar is delivered to the site through the transport vehicle, after the force it will be transported to the dry mortar storage tank, stirring through use of continuous mixer hung on the lower end.

/

/

/
