40hp 55HP Four Wheel Large Farm Tractors WHEELED 48KW

FOB Price

Negotiable

0 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Tractor Characteristics:

1. Chaissis: Whole Frame Structure

2. Engine: Weichai Deutz and Shangchai engine

3. Front axle: CARRARO

4. Rear axle: Construction machinery rear axle

5. Equipped with different kinds of farm implements

6. Strong traction

Main Features

1.Our tractor has a new streamline design and it is beautiful and stylish.

2.Famous diesel engine is used and has the advantage of big power and low fuel consumption.

3.The gearbox of china international large farming tractor 140hp tractor with front loader is designed with a great strength ,wide speed range and a reasonable distribution of grades.

4.Its hydraulic steering system is light and flexible to operate and has a high efficiency.

5.Three point linkage of the tractor has a great lifting force.

6.Therefore a wide range of farming tools,such as rotary tiller,disc plough and disc harrow,can be fitted.

7.There are an extensive range of optional settings,such as cabin,air condition,hydraulic output,shuttle shift and so on.

8.We are proud that we are always listening to our customers.

Type		4×4	4×4	4×4
Exterior size(mm)	Length	5250	5250	5250
	Width	2400	2400	2400
	Height(up to muffle)	3030	3030	3030
Exterior Power(hp)		125	130	135
Engine Speed(r/min)		2400	2400	2400
Wheel Tread(mm)	Front	1900	1900	1900
Wheel Tread(mm)	Rear	(1700~2300 for option)	(1700~2300 for option)	(1700~2300 for option)
Min.Ground Clearance(mm)		400	400	400
Structure Weight(kg)	With Cabin	6850	6850	6850
Structure Weight(kg)	Without Cabin	5800	5800	5800
Turning Radius(m)		4.6-5.7	4.6-5.7	4.6-5.7
Rated Drawbar Pull(kN)		28	28	28
Ballast(kg)	Front	Max.440	Max.440	Max.440
Ballast(kg)	Rear	Max.480	Max.480	Max.480
E N G I N E	Type	Water cooled, vertical, 4 strokes	Water cooled, vertical, 4 strokes	Water cooled, vertical, 4 strokes
	Cylinder	6	6	6
	Bore×stroke(mm)	See the engine specification	See the engine specification	See the engine specification
	Rated power(kW)	92	95.6	99.3
	Rated speed(rpm)	See the engine specification	See the engine specification	See the engine specification
	F.wheel	14.9-28	14.9-28	14.9-28
Tire size	R.wheel	18.4-38	18.4-38	18.4-38
Tire size	16F+16R	16F+16R	16F+16R
gears		2.79~33.91	2.79~33.91	2.79~33.91

Description

>Main features of agricultural tractor
1. Appearance with a new streamlined design, high-grade paint, bright colors, beautiful

and stylish.
2. Match dragged YTO engine power, low fuel consumption, better power ability and economy.
3. Full hydraulic steering system, light and flexible of manipulation, small turning radius and good maneuverability.
4. Full stand-alone power output shaft, which can meet the demand of rotary tillage,

straw, harvesting, planting, fertilizing and other operations.
5.Suspension system to enhance the force, can be suspended with large farm machinery and other agricultural operations.
6.Traction, optional air brake device for towing vehicles for transport operations.
7.1-3 slices optional hydraulic output multi-way valve used tomanipulate the folded target,

flip plow a variety of farm implements and shovel carriers, motor graders and dump trailers.
