Factory direct selling ultra light ultra-thin Xposter machine, hot sales

 Screen goes power off   suddenly

No content displayed after power on for a long time

1.Confirm whether the power supply is normal

2.Press mode button to confirm screen ‘s working mode is normal

3.Confirm that the power supply is normal.If not,please change it.

Some module work abnormal

Some module cannot be light up or work abnormal

1.Replace the defective module

2.Check the bridge board

Display is flickering and cannot controlled

The whole Screen is   flickering

1.Restart the x-poster

2.Check the control card

Parts of the screen doesn’t show content

1/3 or 2/3 of screen   doesn’t show anything

1.Check the power supply’s output end,if damaged,please replace the   power supply.

2.Check bridge board(the board has one red light)if it is with no   lights,then check it have 5V voltage input or not.

Physical Parameter

Pixel Configuration

3in1 SMD

Pixel Pitch (mm)

2.571

Module Dimensions (HxWxD)/(mm)

288 x 216 x 8

Frame Dimensions (HxWxD)/(mm)

1990 x 622 x 35

Display Dimension(HxW)(mm)

1944 x 576

Display Resolution(HxW)

756 x 224

Net weight (kg)

35

Electronic Parameter

Color gray scale (Bit)

14bit
